Xerox DocuColor 2240 Service Manual

09/03
2-304
DC 3535/2240/1632, WC M24
15-376, 15-377
Initial issue
Status Indicator RAPs
15-376 X PIO Non-match Failure 1
Communication Failure.
Procedure
Switch the power off then on. The problem continues.
YN
Return to Service Call Procedures.
Check the connectors on the IIT/IPS PWB (PL 18.3) and the ESS PWB (PL 13.1). If the check
is OK, replace the ESS PWB (PL 13.1). If the problem continues, replace the IIT/IPS PWB (PL
18.3).
15-377 X PIO Non-match Failure 2
Communication Failure.
Procedure
Switch the power off then on. The problem continues.
YN
Return to Service Call Procedures.
Check the connectors on the IIT/IPS PWB (PL 18.3) and the ESS PWB (PL 13.1). If the check
is OK, replace the ESS PWB (PL 13.1). If the problem continues, replace the IIT/IPS PWB (PL
18.3).
