09/03
4-100
DC 3535/2240/1632, WC M24
REP 9.27
Initial issue
Repairs and Adjustments
REP 9.27 Retract Shaft
Parts List on PL 5.4
Replacement
Align Cam and Flag as shown (both on the same side) (Figure 1).
Figure 1 Cam and Flag Alignment
Correct
Alignment
Incorrect
Alignment
