Image Quality
IQ7 Deletions RAP
Initial Actions
Reload with fresh, dry paper of the correct specifications. Paper contaminants (such as fibers
or other particles) may cause spot deletions by interfering with the second transfer. If the prob-
lem occurs with heavyweight paper, ensure that the correct selections are being made on the
print driver and/or UI. If the problem is not resolved, continue with this RAP.
NOTE: Small white deletions with a sharp edge are usually caused by Fuser offsetting. Go to
the IQ16 Spots RAP.
Procedure
The problem is Debris-Centered Deletions.
YN
Enter dC612. Print Test Pattern 2 at 70% coverage for each color. The defect is
present for all colors.
YN
Make several prints of the Test Pattern in the affected color. The defect is present
in approximately the same location on all letter-size prints.
YN
Remove the Drum cartridge for the affected color. Check for light from the
Erase Lamp along the mounting rail left side The Erase lamp is lit.
YN
Examine the surface of the Drum Cartridge. Check for dents, scratches, or
contamination such as fingerprints, etc. The drum is free from damage.
YN
Clean or replace the Drum Cartridge (Machine Consumables).
Switch the affected Drum Cartridge with an adjacent unit. The problem
moves with the cartridge.
YN
Go to the IQ20 RAP and check Flags 1 through 3 for a loose, cor-
roded, or damaged connection.
Replace the Developer (PL 6.2) for the affected color.
Replace the Drum Cartridge (see Machine Consumables in Section 6).
Go to Flag 1 (C), Flag 2 (Y), Flag 3 (M), or Flag 4 (K). Check for a short circuit.
If the wires are OK, replace the Erase Lamp for the affected color. If the prob-
lem persists, Replace the MCU PWB (PL 13.1).
Remove the ROS. Examine the ROS windows for dirt or damage. Clean or replace
as required PL 3.1).
Check the Transfer Belt (PL 5.3) for dirt, damage, or contamination. Clean/replace as
required.
Check the 2nd BTR (PL 2.8) for damage, wear or surface contamination. Clean or replace
if required.
Examine the spot in the center of the DCD. Replace the Developer (PL 6.2) and Toner Car-
tridge for the affected color. If the problem persists, replace the Developer Housing for the
affected color (PL 6.2).
