Xerox DocuColor 2240

09/03
2-325
DC 3535/2240/1632, WC M24
16-311, 16-315
Status Indicator RAPs
Initial issue
16-311 Scanner
Scanner not detected during power up.
Procedure
Switch power off then on. The problem continues.
YN
Return to service call procedures.
Check connections between Scanner and IOT. Service as required (PL 18.3) (PL 18.4).
16-315 IIT Interface
IIT interface error.
Procedure
Switch power off then on. The problem continues.
YN
Return to service call procedures.
Pivot down the HVPS Chassis (REP 1.6) to access I/F PWB.
Check that connections on I/F PWB are secure (PL 9.1).
If problem continues, replace I/F PWB (PL 9.1).
