09/03
2-644
DC 3535/2240/1632, WC M24
116-311, 116-314
Initial issue
Status Indicator RAPs
116-311 ESS Font ROM DIMM #3 Check
A failure was detected when the ESS FONT ROM DIMM #3 was checked.
Procedure
Switch power off then on. The problem continues.
YN
Return to service call procedures.
Pull out and insert the ESS FONT ROM DIMM #3.
If the problem continues, replace the ESS FONT ROM DIMM #3.
116-314 Ethernet Address
A Ethernet error was detected.
Initial Actions
Switch power off then on. If the problem persists, continue with the procedure.
Procedure
Perform GP 3. If the problem continues, reload system software. If the problem persists,
replace the ESS PWB (PL 13.1).
