09/03
2-173
DC 3535/2240/1632, WC M24
8-627, 8-628
Status Indicator RAPs
Initial issue
8-627 Regicon Sample Lateral (A1 Patch-rear)
At A1 (IN) patch detection, the Fast Scan scan position of CYAN color that is the standard for
the rest is incorrect. (Against the MOB SENSOR, the center position of the CYAN pattern is
shifted by ±500µm or more.)
NOTE: Status Code not displayed on UI. Machine operation continues.
Procedure
Check the IBT Belt and Drum for a scratch or contamination. The check is OK.
YN
Replace as required.
Adjust the Color Registration (ADJ 9.6).
8-628 Regicon Sample Lateral (A1 Patch-front)
At A1 (OUT) patch detection, the scan position of CYAN color that is the standard for the rest is
incorrect. (Against the MOB SENSOR, the center position of the CYAN pattern is shifted by
±500µm or more.?
NOTE: Status Code not displayed on UI. Machine operation continues.
Procedure
Check the IBT Belt and Drum for a scratch or contamination. The check is OK.
YN
Replace as required.
Adjust the Color Registration (ADJ 9.6).
