09/03
2-678
DC 3535/2240/1632, WC M24
116-711, 116-712
Initial issue
Status Indicator RAPs
116-711 PLW form synthesis error
Synthesis is impossible because the size/orientation of the PLW form's drawing is different
from that of the paper.
Procedure
Switch power off then on. The problem continues.
YN
Return to service call procedures.
Select the paper with the size and orientation of the registered form.
116-712 Insufficient PLW form capacity
The PLW form/logo data cannot be registered because of the insufficient RAM or Hard Disk
space.
Procedure
Switch power off then on. The problem continues.
YN
Return to service call procedures.
Use the Operation Panel to check the registered forms/logos, and delete unnecessary ones.
Or increase the allocated capacity of the RAM disk.
To Next Page
