09/03
6-26
DC 3535/2240/1632, WC M24
742--xxx Paper Handling NVM List
Initial issue
General Procedures and Information
742-026 Adjust Side Regi (Tray 5) 20 0~50 Side Regi Adjustment (Tray 5) (1bit=0.211mm)
742-027 Adjust Side Regi (Dup) * 0~50 Side Regi Adjustment (Dup) (1bit=0.211mm)
*default=18 for DC2240/1632; 22 for DC3535
742-028 Adjust Lead Regi (All) * 0~40 Lead Regi Adjustment (ALL, Offset value) (1bit=0.2544mm)
*default=20 for DC2240/1632; 16 for DC3535
742-029 Adjust Lead Regi (Tray) * 0~40 Lead Regi Adjustment (P Speed) from Tray (1bit=0.2544mm)
*default=6 for DC2240/1632; 22 for DC3535
742-030 Adjust Lead Regi (Tray) * 0~40 Lead Regi Adjustment (Double Speed) from Tray (1bit=0.2544mm)
*default=21 for DC2240/1632; 20 for DC3535
742-031 Adjust Lead Regi (Tray 5) (Standard
Paper)
* 0~40 Lead Regi Adjustment (P Speed) Standard Paper from Tray 5 (1bit=0.2544mm)
*default=10 for DC2240/1632; 23 for DC3535
742-032 Adjust Lead Regi (Tray 5) (Standard
Paper)
* 0~40 Lead Regi Adjustment (Double Speed) Standard Paper from Tray 5 (1bit=0.2544mm)
*default=21 for DC2240/1632; 20 for DC3535
742-033
DC2240/1632
only
Adjust Lead Regi (Tray 5) (Heavy1) 20 0~40 Lead Regi Adjustment (P Speed) Heavy Weight Paper 1 from Tray 5 (1bit=0.2544mm)
742-034
DC2240/1632
only
Adjust Lead Regi (Tray 5) (Heavy2) 7 0~40 Lead Regi Adjustment (Half Speed) Heavy Weight Paper 2 from Tray 5 (1bit=0.2544mm)
742-035 Adjust Lead Regi (Tray 5) (Heavy 1) * 0~40 Lead Regi Adjustment (Half Speed) Heavy Weight Paper 1 from Tray 5 (1bit=0.2544mm)
*default=7 for DC2240/1632; 20 for DC3535
742-036 Adjust Lead Regi (Tray 5) (Heavy 2) * 0~40 Lead Regi Adjustment (Half Speed) Heavy Weight Paper 2 from Tray 5 (1bit=0.2544mm)
*default=7 for DC2240/1632; 20 for DC3535
742-037 Adjust Lead Regi (Dup) * 0~40 Lead Regi Adjustment (P Speed) (Side2) (1bit=0.2544mm)
*default=21 for DC2240/1632; 22 for DC3535
742-038 Adjust Lead Regi (Dup) * 0~40 Lead Regi Adjustment (Double Speed) (Side2) (1bit=0.2544mm)
*default=21 for DC2240/1632; 20 for DC3535
742-039 Jam Bypass 0 0~255 0=Normal Mode 255=Jam Bypass
742-040 OCT Start Timing (Offset) 112 0~202 OCT (Offset) Start Timing Adjustment (P Speed) (1bit=2.4462 msec.)
742-041 OCT Start Timing (Offset) 59 0~202 OCT (Offset) Start Timing Adjustment (Double Speed)
DC2240/1632: (1bit=1.31136 msec.)
DC3535: (1bit=1.5418 msec.)
741-042
DC3535 only
OCT Start Timing (Offset) 112 0~202 OCT (Offset) Start Timing Adjustment (Heavy1) (1bit=2.4462 msec.)
742-046 Face Up Tray Condition 0 0~1 Face Up Tray Present 0=No 1=Yes
742-047 OCT Start Timing (Home) 17 0~112 OCT (Home) Start Timing Adjustment (P Speed) (1bit=2.4462 msec.)
742-048 OHP Sheet Sensing Condition 1 0~1 Transparency Detection; 1=Detect; 0=Does not detect
742-049 Tray 5 Side Guide min. Data 972 927~1017 Saves the Tray 5 Size Detection min. Value (1bit=1mm)
742-050 Tray 5 Side Guide Max Data 52 7~97 Saves the Tray 5 Size Detection Max Value (1mm/bit)
742-053 Adjust Side Regi Tray 1 20 0~50 Side Regi adjustment of Tray 1 (1bit=0.211mm)
742-055 Pre-T/A Start Timing 3TM-Tray 2 74 0~115 Adjusts the Time between Pre-T/A Starts and Standard Signal (IOT) (303~803 msec.) (1bit=2.4462 msec.)
742-056 Pre-T/A Start Timing 3TM-Tray 3 74 0~115 Adjusts the Time between Pre-T/A Starts and Standard Signal (IOT) (365~865 msec.) (1bit=2.4462 msec.)
742-057 Pre-T/A Start Timing 3TM-Tray 4 74 0~115 Adjusts the Time between Pre-T/A Starts and Standard Signal (IOT) (429~929 msec.) (1bit=2.4462 msec.)
Table 1 Chain 742
Chain-Link Name Default Range Description
