09/03
6-27
DC 3535/2240/1632, WC M24
742--xxx Paper Handling NVM List
General Procedures and Information
Initial issue
742-058 Pre-T/A Start Timing TTM-Tray 2 10 0~16 Adjusts the Time between Pre-T/A Starts and Standard Signal (IOT) (1bit=2.4462 msec.)
742-059 Pre-T/A Start Timing TTM-Tray 3 74 0~115 Adjusts the Time between Pre-T/A Starts and Standard Signal (IOT) (457~957 msec.) (1bit=2.4462 msec.)
742-060 Pre-T/A Start Timing TTM-Tray 4 74 0~115 Adjusts the Time between Pre-T/A Starts and Standard Signal (IOT) (431~931 msec.) (1bit=2.4462 msec.)
742-062 Adjust Pre-Feed Position 3TM-Tray 2 0 0~40 Set time between Feed Out Sensor On and Feed Motor Off (0~400 msec (1bit=10 msec.)
742-063 Adjust Pre-Feed Position 3TM-Tray 3 0 0~40 Set time between Feed Out Sensor On and Feed Motor Off (0~400 msec.). (1bit=10 msec.)
742-064 Adjust Pre-Feed Position 3TM-Tray 4 0 0~40 Set time between Feed Out Sensor On and Feed Motor Off (0~400 msec.). (1bit=10 msec.)
742-065 Adjust Pre-Feed Position TTM-Tray 2 0 0~40 Set time between Feed Out Sensor On and Feed Motor Off (0~400 msec.). (1bit=10 msec.)
742-066 Adjust Pre-Feed Position TTM-Tray 3 0 0~40 Set time between Feed Out Sensor On and Feed Motor Off (0~400 msec.). (1bit=10 msec.)
742-067 Adjust Pre-Feed Position TTM-Tray 4 37 10~50 Set time between Feed Out Sensor On and Feed Motor Off (100~500 msec.). (1bit=10 msec.) Default=370ms
742-068 Adjust Pre-Feed Position 1TM-1 0 0~40 Set time between Feed Out Sensor On and Feed Motor Off (0~400 msec.). (1bit=10 msec.)
742-069 Main Feed Start Timing 3TM-Tray 2 20 0~44 Set time between Main Feed Start and the Pre-T/A (330~830 msec.). (1bit=10 msec.)
742-070 Main Feed Start Timing 3TM-Tray 3 20 0~44 Sets time between Main Feed Start and Pre-T/A (570~1070 msec.). (1bit=10 msec.)
742-071 Main Feed Start Timing 3TM-Tray 4 20 0~44 Sets time between Main Feed Start and Pre-T/A (810~1310 msec.). (1bit=10 msec.)
742-072 Main Feed Start Timing TTM-Tray 2 20 0~44 Sets time between Main Feed Start and Pre-T/A (330~830 msec.). (1bit=10 msec.)
742-073 Main Feed Start Timing TTM-Tray 3 20 0~44 Sets time between Main Feed Start and Pre-T/A (780~1280 msec.). (1bit=10 msec.)
742-074 Main Feed Start Timing TTM-Tray 4 20 0~44 Sets time between Main Feed Start and Pre-T/A (1410~1910 msec.). (1bit=10 msec.)
742-076 Adjust Side Regi Tray 2 20 0~50 Side Regi adjustment of Tray 2 (1bit=0.211mm)
742-077 Adjust Side Regi Tray 3 20 0~50 Side Regi adjustment of Tray 3 (1bit=0.211mm)
742-078 Adjust Side Regi Tray 4 20 0~50 Side Regi adjustment votary 4 (1bit=0.211mm)
742-079 Adjust Side Regi Tray Module All 25 0~50 Side Regi adjustment of Trays 2, 3, 4 (Batch adjustment) (1bit=0.211mm)
742-080 Paper remaining (calc) 3TM-Tray 2 0 0~4000 Saves the cumulative Lift-up time from Tray insertion (Calculation of remaining paper level detected).
742-081 Paper remaining (calc) 3TM-Tray 3 0 0~4000 Saves the cumulative Lift-up time from Tray insertion (Calculation of remaining paper level detected).
742-082 Paper remaining (calc) 3TM-Tray 4 0 0~4000 Saves the cumulative Lift-up time from Tray insertion (Calculation of remaining paper level detected).
742-083 Paper remaining (calc) TTM-Tray 2 0 0~4000 Saves the cumulative Lift-up time from Tray insertion (Calculation of remaining paper level detected).
742-084 Paper remaining (calc) TTM-Tray 3 0 0~12000 Saves the cumulative Lift-up time from Tray insertion (Calculation of remaining paper level detected).
742-085 Paper remaining (calc) TTM-Tray 4 0 0~15000 Saves the cumulative Lift-up time from Tray insertion (Calculation of remaining paper level detected).
742-087 OCT present 1 0~1 0=Not available; 1=Available
742-088 Dup On Timing (From Regi Start) 20 0~40 Synchronize adjustment to be same as the Regi Clutch at Regi Start (Double Speed)
DC2240/1632: (1bit=1.31136 msec.)
DC3535: (1bit=1.5418 msec.)
742-089 OCT Start Timing (Home) 17 0~112 OCT (Home) Start Timing Adjustment (Double Speed)
DC2240/1632: (1bit=1.31136 msec.)
DC3535: (1bit=1.5418 msec.)
742-090
DC3535 only
OCT Start Timing (Home) 17 0~112 OCT (Home) Start Timing Adjustment (Heavy 1) (1bit=2.4462 msec.)
742-093
DC2240/1632
Pre-T/A Start Timing 3TM-Tray 2 139 0~215 Adjusts the Time between Pre-T/A Starts and Standard Signal (IOT) (303~803 msec.) (1bit=1.31136 msec.)
742-093
DC3535
Pre-T/A Start Timing 3TM-Tray 2 118 0~183 Adjusts the Time between Pre-T/A Starts and Standard Signal (IOT) (303~803 msec.) (1bit=1.5418 msec.)
742-094
DC2240/1632
Pre-T/A Start Timing 3TM-Tray 3 139 0~215 Adjusts the Time between Pre-T/A Starts and Standard Signal (IOT) (365~865 msec.) (1bit=1.31136 msec.)
Table 1 Chain 742
Chain-Link Name Default Range Description
