Xerox DocuColor 2240

09/03
6-74
DC 3535/2240/1632, WC M24
790-xxx ESS Panel Display Setting NVM List
Initial issue
General Procedures and Information
790-013 Tray 5 Paper sizes _8 13 0~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
790-014 Tray 5 Paper sizes _9 16 0~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
790-015 Tray 5 Paper sizes _10 15 0~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
790-016 Tray 5 Paper sizes _11 7 0~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
790-050 Pre Set Tray 1 1 1~5 Pre-set tray setting on Basic screen - 1=Tray 1; 2=Tray 2; 3=Tray 3; 4=Tray 4; 5=Tray 5
790-051 Pre Set Tray 2 2 1~5 1=Tray 1; 2=Tray 2; 3=Tray 3; 4=Tray 4; 5=Tray 5
790-052 Pre Set Tray 3 3 1~5 1=Tray 1; 2=Tray 2; 3=Tray 3; 4=Tray 4; 5=Tray 5
790-060 Pre Set Magnification 1 1 1~7 1~7=Fixed Magnification 1~7
790-061 Pre Set Magnification 2 2 1~7 1~7=Fixed Magnification 1~7
790-070 Default Tray Setting in Copy Mode 0 0~5 0=Auto; 1=Tray 1; 2=Tray 2; 3=Tray 3; 4=Tray 4; 5=Tray 5
790-071 Tray at Auto Cancellation 1 1=Tray 1; 2=Tray 2; 3=Tray 3; 4=Tray 4
790-072 Default Magnification Setting in Copy
Mode
0 0~8 0=100%; 1~7=Fixed Magnification presets; 8=Auto
790-073 Fixed Magnification 1 Setting in Copy
Mode
1 1~18 1=25.0; 2=35.3; 3=50.0; 4=57.7; 5=61.2 6=64.7; 7=70.7; 8=81.6; 9=86.6 10=115.4; 11=122.5; 12=129.4
13=141.4; 14=163.2; 15=173.2 16=200.0; 17=282.8; 18=400.0%
790-074 Fixed Magnification 2 Setting in Copy
Mode
3 1~18 1=25.0; 2=35.3; 3=50.0; 4=57.7; 5=61.2 6=64.7; 7=70.7; 8=81.6; 9=86.6 10=115.4; 11=122.5; 12=129.4
13=141.4; 14=163.2; 15=173.2 16=200.0; 17=282.8; 18=400.0%
790-075 Fixed Magnification 3 Setting in Copy
Mode
6 1~18 1=25.0; 2=35.3; 3=50.0; 4=57.7; 5=61.2 6=64.7; 7=70.7; 8=81.6; 9=86.6 10=115.4; 11=122.5; 12=129.4
13=141.4; 14=163.2; 15=173.2 16=200.0; 17=282.8; 18=400.0%
790-076 Fixed Magnification 4 Setting in Copy
Mode
7 1~18 1=25.0; 2=35.3; 3=50.0; 4=57.7; 5=61.2 6=64.7; 7=70.7; 8=81.6; 9=86.6 10=115.4; 11=122.5; 12=129.4
13=141.4; 14=163.2; 15=173.2 16=200.0; 17=282.8; 18=400.0%
790-077 Fixed Magnification 5 Setting in Copy
Mode
12 1~18 1=25.0; 2=35.3; 3=50.0; 4=57.7; 5=61.2 6=64.7; 7=70.7; 8=81.6; 9=86.6 10=115.4; 11=122.5; 12=129.4
13=141.4; 14=163.2; 15=173.2 16=200.0; 17=282.8; 18=400.0%
790-078 Fixed Magnification 6 Setting in Copy
Mode
13 1~18 1=25.0; 2=35.3; 3=50.0; 4=57.7; 5=61.2 6=64.7; 7=70.7; 8=81.6; 9=86.6 10=115.4; 11=122.5; 12=129.4
13=141.4; 14=163.2; 15=173.2 16=200.0; 17=282.8; 18=400.0%
790-079 Fixed Magnification 7 Setting in Copy
Mode
18 1~18 1=25.0; 2=35.3; 3=50.0; 4=57.7; 5=61.2 6=64.7; 7=70.7; 8=81.6; 9=86.6 10=115.4; 11=122.5; 12=129.4
13=141.4; 14=163.2; 15=173.2 16=200.0; 17=282.8; 18=400.0%
790-090 Default Color Mode 0 0~5 0=None; 1=Auto; 2=B/W; 3=4 Colors; 4=Single Color; 5=Dual Color
790-091 Default Single Color Selection 1 0~12 1~6=Fixed Registered Color 1~6; 7~12=User Registered Color 1~6
Table 1 Chain 790
Chain-Link Name Default Range Description
