Xerox DocuColor 2240 Service Manual

09/03
6-13
DC 3535/2240/1632, WC M24
700-xxx ESS Configuration NVM List
General Procedures and Information
Initial issue
700-321 SEEPROM Product # (1st digit) - - Alphanumeric (ASCII)
700-322 SEEPROM Product # (2nd digit) - - Alphanumeric (ASCII)
700-323 SEEPROM Product # (3rd digit) - - Alphanumeric (ASCII)
700-324 SEEPROM Product #(4th digit) - - Alphanumeric (ASCII)
700-325 Battery Backup SRAM Product # (1st
digit)
- - Alphanumeric (ASCII)
700-326 Battery Backup SRAM Product # (2nd
digit)
- - Alphanumeric (ASCII)
700-327 Battery Backup SRAM Product # (3rd
digit)
- - Alphanumeric (ASCII)
700-328 Battery Backup SRAM Product # (4th
digit)
- - Alphanumeric (ASCII)
700-329 SEEPROM Product Code (1st digit) 76 - Alphanumerics (ASCII)
700-330 SEEPROM Product Code (2nd digit) 86 - Alphanumerics (ASCII)
700-331
DC2240/1632
SEEPROM Product Code (3rd digit) XC=69
XE=70
- Alphanumerics (ASCII)
700-331
DC3535
SEEPROM Product Code (3rd digit) XC=71
XE=72
- Alphanumerics (ASCII)
700-332 SEEPROM Product Code (4th digit) 32 - Alphanumerics (ASCII)
700-333 SEEPROM Product Code (5th digit) 32 - Alphanumerics (ASCII)
700-334 SEEPROM Product Code (6th digit) 32 - Alphanumerics (ASCII)
700-335 SEEPROM Product Code (7th digit) 32 - Alphanumerics (ASCII)
700-336 SEEPROM Product Code (8th digit) 32 - Alphanumerics (ASCII)
700-337 Device Configuration 15 - Set at factory. It allocates bits in the following sequence into P(rinter), F(ax), C(opy), S(can) respectively:
P=0x01, F=0x02, C=0x04, S=0x08
700-338 Market Region (SEEPROM) XC=2
XE=3
1~4 1=FX; 2=XC; 3=XE; 4=AP
700-339 IOT ROM Major version - - (Auto Setting)
700-340 IOT ROM Minor version - - (Auto Setting)
700-341 IOT ROM Revision version - - (Auto Setting)
700-342 Sys Main ROM Major - - (Auto Setting)
700-343 Sys Main ROM Minor - - (Auto Setting)
700-344 Sys Main ROM Revision - - (Auto Setting)
700-348 IIT ROM Major - - (Auto Setting)
700-349 IIT ROM Minor - - (Auto Setting)
700-350 IIT ROM Revision - - (Auto Setting)
700-351 DADF ROM Major - - (Auto Setting)
700-352 DADF ROM Minor - - (Auto Setting)
700-353 DADF ROM Revision - - (Auto Setting)
700-354 UI Frame ROM Major - - (Auto Setting)
700-355 UI Frame ROM Minor - - (Auto Setting)
700-356 UI Frame ROM Revision - - (Auto Setting)
Table 1 Chain 700
Chain-Link Name Default Range Description

Xerox DocuColor 2240 Specifications

General

Brand	Xerox
Model	DocuColor 2240
Category	All in One Printer
Language	English
