Xerox DocuColor 2240 Service Manual

09/03
2-81
DC 3535/2240/1632, WC M24
5-110
Status Indicator RAPs
Initial issue
5-110 Registration Sensor On
The Registration Sensor did not detect a document within 800 msec. after the Feed Motor
energized.
Initial Actions
• This fault can be caused by the following operator errors:
– Pulling the document out of the DADF while it is being fed.
– Loading too many documents or documents that are not in specification for the
DADF (incorrect size or quality, staples or paper clips, etc.).
Instruct the operator how to operate the DADF.
• Ensure document path is clear. Look for pieces of paper that could be blocking the Regis-
tration Sensor or the document path.
• Ensure Feed and Nudger Rolls are free of contamination and wear (PL 20.4).
Procedure
Clear the jam if one exists. Place a document in the DADF and press the Start button. The
document prefeeds into the DADF.
YN
Remove the following:
• Front Cover (PL 20.1)
• Entrance Tray (PL 20.1)
• Lower Chute Assembly (REP 5.8)
• Rear Cover (REP 5.18)
Visually check the fingers of the Set Gate (PL 20.5). The Set Gate is in the raised posi-
tion.
YN
Go to the 5-700 Set Gate Solenoid RAP.
Enter dC330 [005-011]. Select Start. The Set Gate goes to the lowered position.
YN
Go to the 5-700 Set Gate Solenoid RAP.
Attempt to feed another document. The Feed Motor energizes.
YN
Go to the 5-701 Feed Motor RAP and check the circuit of the Feed Motor.
Check the Fuse F3 on the DADF Control PWB. The Fuse is good.
YN
If a fuse is not available, replace the DADF Control PWB (PL 20.3).
Check the +24 VDC wires on the Feed Motor for a short circuit to frame.
If the wires are good, and the problem continues, replace the Feed Motor (PL 20.4).
Access the Feed Rolls (REP 5.7). Check the Feed Roll Drives (Feed Belt, Pulleys, etc.).
Repair as required (PL 20.4).
Clear the jam. Enter dC330 [005-110]. The display indicates H.
YN
Go to the 5-702 Registration Sensor RAP
Open the Document Feed Assembly and block the Registration Sensor with a sheet of paper.
The display changes to L.
YN
Go to the 5-702 Registration Sensor RAP
Check the following:
• Nudger Roll (PL 20.4) for wear or damage
• The bracket in which the Nudger Rolls are mounted. Check that the bracket is not bent or
deformed. Reform the bracket if necessary.
If the problem continues, replace the Registration Sensor (PL 20.5). If the problem still contin-
ues, replace the DADF Control PWB (PL 20.3).
A
A
