09/03
6-81
DC 3535/2240/1632, WC M24
790-xxx ESS Panel Display Setting NVM List
General Procedures and Information
Initial issue
790-265 Fixed Size 8 Slow Scan NULL 15~432 15~432mm
790-266 Fixed Size 9 Fast Scan NULL 15~297 15~297mm
790-267 Fixed Size 9 Slow Scan NULL 15~432 15~432mm
790-268 Fixed Size 10 Fast Scan NULL 15~297 15~297mm
790-269 Fixed Size 10 Slow Scan NULL 15~432 15~432mm
790-270 Fixed Size 11 Fast Scan NULL 15~297 15~297mm
790-271 Fixed Size 11 Slow Scan NULL 15~432 15~432mm
790-272 Default [Document Orientation] in
SCAN Mode
0 0~1 0=Head to Top; 1=Head to Left
790-273 Default 1 setting of SCAN Fixed magni-
fication
3 0~18 1=25.0; 2=35.3; 3=50.0; 4=57.7; 5=61.2 6=64.7; 7=70.7; 8=81.6; 9=86.6 10=115.4; 11=122.5; 12=129.4
13=141.4; 14=163.2; 15=173.2 16=200.0; 17=282.8; 18=400.0%
790-274 Default 2 setting of SCAN Fixed magni-
fication
7 0~18 1=25.0; 2=35.3; 3=50.0; 4=57.7; 5=61.2 6=64.7; 7=70.7; 8=81.6; 9=86.6 10=115.4; 11=122.5; 12=129.4
13=141.4; 14=163.2; 15=173.2 16=200.0; 17=282.8; 18=400.0%
790-275 Default 3 setting of SCAN Fixed magni-
fication
8 0~18 1=25.0; 2=35.3; 3=50.0; 4=57.7; 5=61.2 6=64.7; 7=70.7; 8=81.6; 9=86.6 10=115.4; 11=122.5; 12=129.4
13=141.4; 14=163.2; 15=173.2 16=200.0; 17=282.8; 18=400.0%
790-276 Default 4 setting of SCAN Fixed magni-
fication
9 0~18 1=25.0; 2=35.3; 3=50.0; 4=57.7; 5=61.2 6=64.7; 7=70.7; 8=81.6; 9=86.6 10=115.4; 11=122.5; 12=129.4
13=141.4; 14=163.2; 15=173.2 16=200.0; 17=282.8; 18=400.0%
790-277 Default 5 setting of SCAN Fixed magni-
fication
10 0~18 1=25.0; 2=35.3; 3=50.0; 4=57.7; 5=61.2 6=64.7; 7=70.7; 8=81.6; 9=86.6 10=115.4; 11=122.5; 12=129.4
13=141.4; 14=163.2; 15=173.2 16=200.0; 17=282.8; 18=400.0%
790-278 Default 6 setting of SCAN Fixed magni-
fication
11 0~18 1=25.0; 2=35.3; 3=50.0; 4=57.7; 5=61.2 6=64.7; 7=70.7; 8=81.6; 9=86.6 10=115.4; 11=122.5; 12=129.4
13=141.4; 14=163.2; 15=173.2 16=200.0; 17=282.8; 18=400.0%
790-279 Default 7 setting of SCAN Fixed magni-
fication
13 0~18 1=25.0; 2=35.3; 3=50.0; 4=57.7; 5=61.2 6=64.7; 7=70.7; 8=81.6; 9=86.6 10=115.4; 11=122.5; 12=129.4
13=141.4; 14=163.2; 15=173.2 16=200.0; 17=282.8; 18=400.0%
790-280 Output Size 1 18 1~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF
790-281 Output Size 2 17 1~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF
790-282 Output Size 3 11 1~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF
790-283 Output Size 4 10 1~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF
790-284 Output Size 5 20 1~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF
790-285 Output Size 6 22 1~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF
790-286 Output Size 7 13 1~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF
Table 1 Chain 790
Chain-Link Name Default Range Description
