Xerox DocuColor 2240 Service Manual

09/03
6-84
DC 3535/2240/1632, WC M24
810-xxx ESS Copy Service Setting
Initial issue
General Procedures and Information
810-027 User Preset Color 3 - M component 0 0~128 0%~100%; 0.78%/bit
810-028 User Preset Color 3 - C component 0 0~128 0%~100%; 0.78%/bit
810-029 User Preset Color 4 - Y component 0 0~128 0%~100%; 0.78%/bit
810-030 User Preset Color 4 - M component 0 0~128 0%~100%; 0.78%/bit
810-031 User Preset Color 4 - C component 0 0~128 0%~100%; 0.78%/bit
810-032 User Preset Color 5 - Y component 0 0~128 0%~100%; 0.78%/bit
810-033 User Preset Color 5 - M component 0 0~128 0%~100%; 0.78%/bit
810-034 User Preset Color 5 - C component 0 0~128 0%~100%; 0.78%/bit
810-035 User Preset Color 6 - Y component 0 0~128 0%~100%; 0.78%/bit
810-036 User Preset Color 6 - M component 0 0~128 0%~100%; 0.78%/bit
810-037 User Preset Color 6 - C component 0 0~128 0%~100%; 0.78%/bit
810-038 Background Suppression “Vivid” 0 0~1 0=disable; 1=enable
810-039 Density Adjustment “Vivid” 2 0~6 0=Lighter 3; 1=Lighter 2; 2=Lighter 1; 3=Normal; 4=Darker 1; 5=Darker 2; 6=Darker 3
810-040 Color balance (Y low density) “Vivid” 3 0~6 0=Lighter 3; 1=Lighter 2; 2=Lighter 1; 3=Normal; 4=Darker 1; 5=Darker 2; 6=Darker 3
810-041 Color balance (Y med. density) “Vivid” 3 0~6 0=Lighter 3; 1=Lighter 2; 2=Lighter 1; 3=Normal; 4=Darker 1; 5=Darker 2; 6=Darker 3
810-042 Color balance (Y high density) “Vivid” 3 0~6 0=Lighter 3; 1=Lighter 2; 2=Lighter 1; 3=Normal; 4=Darker 1; 5=Darker 2; 6=Darker 3
810-043 Color balance (M low density) “Vivid” 3 0~6 0=Lighter 3; 1=Lighter 2; 2=Lighter 1; 3=Normal; 4=Darker 1; 5=Darker 2; 6=Darker 3
810-044 Color balance (M med. density) “Vivid” 3 0~6 0=Lighter 3; 1=Lighter 2; 2=Lighter 1; 3=Normal; 4=Darker 1; 5=Darker 2; 6=Darker 3
810-045 Color balance (M high density) “Vivid” 3 0~6 0=Lighter 3; 1=Lighter 2; 2=Lighter 1; 3=Normal; 4=Darker 1; 5=Darker 2; 6=Darker 3
810-046 Color balance (C low density) “Vivid” 3 0~6 0=Lighter 3; 1=Lighter 2; 2=Lighter 1; 3=Normal; 4=Darker 1; 5=Darker 2; 6=Darker 3
810-047 Color balance (C med. density) “Vivid” 3 0~6 0=Lighter 3; 1=Lighter 2; 2=Lighter 1; 3=Normal; 4=Darker 1; 5=Darker 2; 6=Darker 3
810-048 Color balance (C high density) “Vivid” 3 0~6 0=Lighter 3; 1=Lighter 2; 2=Lighter 1; 3=Normal; 4=Darker 1; 5=Darker 2; 6=Darker 3
810-049 Color balance (K low density) “Vivid” 3 0~6 0=Lighter 3; 1=Lighter 2; 2=Lighter 1; 3=Normal; 4=Darker 1; 5=Darker 2; 6=Darker 3
810-050 Color balance (K med. density) “Vivid” 3 0~6 0=Lighter 3; 1=Lighter 2; 2=Lighter 1; 3=Normal; 4=Darker 1; 5=Darker 2; 6=Darker 3
810-051 Color balance (K high density) “Vivid” 3 0~6 0=Lighter 3; 1=Lighter 2; 2=Lighter 1; 3=Normal; 4=Darker 1; 5=Darker 2; 6=Darker 3
810-052 Color Shift “Vivid” 2 0~4 0=-20 degrees; 1=-10 degrees; 2=0 degrees; 3=+10 degrees; 4=+20 degrees
810-053 Color Saturation “Vivid” 0 0~4 0=Higher 2; 1=Higher 1; 2=Normal; 3=Lower 1; 4=Lower 2
810-054 Sharpness “Vivid” 2 0~4 0=Sharper 2; 1=Sharper 1; 2=Normal; 3=Softer 1; 4=Softer 2
810-055 Contrast “Vivid” 2 0~4 0=Stronger 2; 1=Stronger 1; 2=Normal; 3=Softer 1; 4=Softer 2
810-056 Background Suppression MERIHARI
Copy
0 0~1 0=disable; 1=enable
810-057 Density Adjustment MERIHARI Copy 4 0~6 0=Lighter 3; 1=Lighter 2; 2=Lighter 1; 3=Normal; 4=Darker 1; 5=Darker 2; 6=Darker 3
810-058 Color balance (Y low density) MERI-
HARI Copy
0 0~6 0=Lighter 3; 1=Lighter 2; 2=Lighter 1; 3=Normal; 4=Darker 1; 5=Darker 2; 6=Darker 3
810-059 Color balance (Y med. density) MERI-
HARI Copy
3 0~6 0=Lighter 3; 1=Lighter 2; 2=Lighter 1; 3=Normal; 4=Darker 1; 5=Darker 2; 6=Darker 3
810-060 Color balance (Y high density) MERI-
HARI Copy
6 0~6 0=Lighter 3; 1=Lighter 2; 2=Lighter 1; 3=Normal; 4=Darker 1; 5=Darker 2; 6=Darker 3
810-061 Color balance (M low density) MERI-
HARI Copy
0 0~6 0=Lighter 3; 1=Lighter 2; 2=Lighter 1; 3=Normal; 4=Darker 1; 5=Darker 2; 6=Darker 3
810-062 Color balance (M med. density) MERI-
HARI Copy
3 0~6 0=Lighter 3; 1=Lighter 2; 2=Lighter 1; 3=Normal; 4=Darker 1; 5=Darker 2; 6=Darker 3
Table 1 Chain 810
Chain/Link Name Default Range Description
