Xerox DocuColor 2240 Service Manual

09/03
6-127
DC 3535/2240/1632, WC M24
GP 5
General Procedures and Information
Initial issue
016 Tonal Signal Output 1850Hz
017 Tonal Signal Output 2100Hz
019 DTMF Signal Output Dual Tone 1
020 DTMF Signal Output Dual Tone 2
021 DTMF Signal Output Dual Tone 3
022 DTMF Signal Output Dual Tone 4
023 DTMF Signal Output Dual Tone 5
024 DTMF Signal Output Dual Tone 6
025 DTMF Signal Output Dual Tone 7
026 DTMF Signal Output Dual Tone 8
027 DTMF Signal Output Dual Tone 9
028 DTMF Signal Output Dual Tone 0
029 DTMF Signal Output Dual Tone *
030 DTMF Signal Output Dual Tone #
031 DTMF Signal Output Dual Tone A
032 DTMF Signal Output Dual Tone B
033 DTMF Signal Output Dual Tone C
034 DTMF Signal Output Dual Tone D
035 V.21 (H) Signal Output HDLC Flag
036 V.27ter Signal Output 2400 bps (HDLC Flag)
037 V.27ter Signal Output 4800 bps (HDLC Flag)
038 V.29 Signal Output 7200 bps (HDLC Flag)
039 V.29 Signal Output 9600 bps (HDLC Flag)
040 V.17 Signal Output 7200 bps (HDLC Flag)
041 V.17 Signal Output 9600 bps (HDLC Flag)
042 V.17 Signal Output 12000 bps (HDLC Flag)
043 V.17 Signal Output 14400 bps (HDLC Flag)
080 V.8 Signal Output ANSam
081 V.8 Signal Output CM
082 V.8 Signal Output JM
083 V.8 Signal Output INFOc
084 V.8 Signal Output INFOa
085 V.8 Signal Output PPh+ALT
096 V.34 Signal Output 2400/2400 (HDLC Flag)
097 V.34 Signal Output 4800/2400 (HDLC Flag)
098 V.34 Signal Output 7200/2400 (HDLC Flag)
099 V.34 Signal Output 9600/2400 (HDLC Flag)
100 V.34 Signal Output 12000/2400 (HDLC Flag)
101 V.34 Signal Output 14400/2400 (HDLC Flag)
102 V.34 Signal Output 16800/2400 (HDLC Flag)
103 V.34 Signal Output 19200/2400 (HDLC Flag)
Table 1 Fax Diagnostic signal numbers
Signal No. Output Description
104 V.34 Signal Output 21600/2400 (HDLC Flag)
106 V.34 Signal Output 4800/2743 (HDLC Flag)
107 V.34 Signal Output 7200/2743 (HDLC Flag)
108 V.34 Signal Output 9600/2743 (HDLC Flag)
109 V.34 Signal Output 12000/2743 (HDLC Flag)
110 V.34 Signal Output 14400/2743 (HDLC Flag)
111 V.34 Signal Output 16800/2743 (HDLC Flag)
112 V.34 Signal Output 19200/2743 (HDLC Flag)
113 V.34 Signal Output 21600/2743 (HDLC Flag)
114 V.34 Signal Output 24000/2743 (HDLC Flag)
117 V.34 Signal Output 4800/3000 (HDLC Flag)
118 V.34 Signal Output 7200/3000 (HDLC Flag)
119 V.34 Signal Output 9600/3000 (HDLC Flag)
120 V.34 Signal Output 12000/3000 (HDLC Flag)
121 V.34 Signal Output 14400/3000 (HDLC Flag)
122 V.34 Signal Output 16800/3000 (HDLC Flag)
123 V.34 Signal Output 19200/3000 (HDLC Flag)
124 V.34 Signal Output 21600/3000 (HDLC Flag)
125 V.34 Signal Output 24000/3000 (HDLC Flag)
126 V.34 Signal Output 26400/3000 (HDLC Flag)
127 V.34 Signal Output 28800/3000 (HDLC Flag)
129 V.34 Signal Output 4800/3200 (HDLC Flag)
130 V.34 Signal Output 7200/3200 (HDLC Flag)
131 V.34 Signal Output 9600/3200 (HDLC Flag)
132 V.34 Signal Output 12000/3200 (HDLC Flag)
133 V.34 Signal Output 14400/3200 (HDLC Flag)
134 V.34 Signal Output 16800/3200 (HDLC Flag)
135 V.34 Signal Output 19200/3200 (HDLC Flag)
136 V.34 Signal Output 21600/3200 (HDLC Flag)
137 V.34 Signal Output 24000/3200 (HDLC Flag)
138 V.34 Signal Output 26400/3200 (HDLC Flag)
139 V.34 Signal Output 28800/3200 (HDLC Flag)
140 V.34 Signal Output 31200/3200 (HDLC Flag)
142 V.34 Signal Output 4800/3429 (HDLC Flag)
143 V.34 Signal Output 7200/3429 (HDLC Flag)
144 V.34 Signal Output 9600/3429 (HDLC Flag)
145 V.34 Signal Output 12000/3429 (HDLC Flag)
146 V.34 Signal Output 14400/3429 (HDLC Flag)
147 V.34 Signal Output 16800/3429 (HDLC Flag)
148 V.34 Signal Output 19200/3429 (HDLC Flag)
149 V.34 Signal Output 21600/3429 (HDLC Flag)
Table 1 Fax Diagnostic signal numbers
Signal No. Output Description
