Xerox DocuColor 2240

09/03
2-383
DC 3535/2240/1632, WC M24
16-981, 16-982
Status Indicator RAPs
Initial issue
16-981 Full HDD
Full status was detected at HDD access. Full status was not cleared even during waiting for
timing. One or more pages are already stored.
Procedure
Switch power off then on. The problem continues.
YN
Return to service call procedures.
If the problem continues, reload software.
If the problem continues, replace the HDD (PL 13.1).
16-982 Full HDD
Full status was detected at HDD access. Full status was not cleared even during waiting for
timing. No pages can be stored.
Procedure
Switch power off then on. The problem continues.
YN
Return to service call procedures.
Check the HDD harness connection (PL 13.1). If the problem continues, replace the HDD (PL
13.1).
