09/03
4-141
DC 3535/2240/1632, WC M24
REP 12.19
Repairs and Adjustments
Initial issue
4. Remove Rear Rack (Figure 3).
Figure 3 Removing Rear Rack
5. Remove Front Rack (Figure 4).
Figure 4 Removing Front Rack
1
Remove
Thumbscrew
2
Lift to
Remove
Rack
1
Remove
Thumbscrew
2
Lift to
Remove
Rack
