NTERRUPTS
Updated Table 53: List of vectors.
ADC:
Removed JADSTART from the whole section.
Updated ADC supply requirements in Section 13.2: ADC main
features and Figure 28: ADC block diagram
Renamed section “Analog Reference from the PMU” into Section :
Analog reference for the ADC internal voltage regulator and content
updated. Modified Section 14.4.2: Calibration (ADCAL).
In Section 13.11: Temperature sensor and internal reference voltage,
changed 110 °C into 130 °C.
Updated AWDCH[4:0] and SCANDIR descriptions in Section 13.15.4:
ADC configuration register 1 (ADC_CFGR1).
DAC:
Added Section : Independent trigger with single LFSR generation and
Section : Independent trigger with single triangle generation in
Section 15.5.2: DAC channel conversion.
COMP:
Updated Figure 61: Comparator 1 and 2 block diagrams.
Updated bits named in Figure 61: Comparator 1 and 2 block
diagrams. Renamed COMP1_CSR and COMP2_CSR bits.
LCD
Updated COM and SEG output pin functions in Section 17.4.7: COM
and SEG multiplexing. Updated note in Section 17.7.1: LCD control
register (LCD_CR).
TIM2/3:
Updated Section 21.4.19: TIM2 option register (TIM2_OR).
Changed all registers to 16-bit length.
TIM21/22:
Updated Figure 147: General-purpose timer block diagram
(TIM21/22).
Added Section 22.4.2: TIM21/22 control register 2 (TIMx_CR2).
USART
Updated CTSE bit description in Section 29.8.3: Control register 3
(USART_CR3).
DEBUG
Replaced DBG_TIM20_STOP and DBG_TIM21_STOP by
DBG_TIM21_STOP and DBG_TIM22_STOP, respectively.
Updated REV_ID in Section 33.4.1: MCU device ID code.
