General-purpose timers (TIM2/TIM3) RM0367

546/1043 RM0367 Rev 7

Refer to Section 2.2 on page 58 for the register boundary addresses.

0x2C

TIMx_ARR ARR[15:0]

Reset value 0000000000000000

0x30 Res.

0x34

TIMx_CCR1 CCR1[15:0]

Reset value 0000000000000000

0x38

TIMx_CCR2 CCR2[15:0]

Reset value 0000000000000000

0x3C

TIMx_CCR3 CCR3[15:0]

Reset value 0000000000000000

0x40

TIMx_CCR4 CCR4[15:0]

Reset value 0000000000000000

0x44 Res.

0x48

TIMx_DCR

Res.

DBL[4:0]

Res.

DBA[4:0]

Reset value 00000 00000

0x4C

TIMx_DMAR DMAB[15:0]

Reset value 0000000000000000

0x50

TIM2_OR

Res.

TI4_RMP

ETR_RMP

Reset value 0000

0x50

TIM3_OR

Res.

TI_RMP ETR_RMP

Reset value 00000

Table 101. TIM2/3 register map and reset values (continued)

Offset Register

1514131211109876543210
