Device electronic signature RM0367
972/1043 RM0367 Rev 7
Base address: 0x1FF8 0050
Address offset: 0x00
Read only = 0xXXXX XXXX where X is factory-programmed
Address offset: 0x04
Read only = 0xXXXX XXXX where X is factory-programmed
Address offset: 0x14
Read only = 0xXXXX XXXX where X is factory-programmed
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
U_ID(31:16)
rrrrrrrrrrrrrrrr
1514131211109876543210
U_ID(15:0)
rrrrrrrrrrrrrrrr
Bits 31:0 U_ID(31:24): WAF_NUM[7:0]
Wafer number (8-bit unsigned number)
U_ID
(23:0): LOT_NUM[55:32]
Lot number (ASCII code)
63 62 61 60 59 58 57 56 55 54 53 52 51 50 49 48
U_ID(63:48)
rrrrrrrrrrrrrrrr
47 46 45 44 43 42 41 40 39 38 37 36 35 34 33 32
U_ID(47:32)
rrrrrrrrrrrrrrrr
Bits 63:32 U_ID(63:32): LOT_NUM[31:0]
Lot number (ASCII code)
95 94 93 92 91 90 89 88 87 86 85 84 83 82 81 80
U_ID(95:80)
rrrrrrrrrrrrrrrr
79 78 77 76 75 74 73 72 71 70 69 68 67 66 65 64
U_ID(79:64)
rrrrrrrrrrrrrrrr
Bits 95:64 U_ID(95:64): 95:64 unique ID bits
