Xerox DocuColor 2240 Service Manual

09/03
6-18
DC 3535/2240/1632, WC M24
715-xxx IIT NVM List
Initial issue
General Procedures and Information
715-214 Undercolor Data for B/W 0 0~255 Speed Priority AE/Fixed background color data in B/W Register Mode
715-215 Undercolor Data for Color 0 0~255 Speed Priority AE/Fixed background color data in Color Register Mode
715-216 Undercolor removal level for color copy 0 0~4 0=std. background suppression; 1=level 1; 2=level 2; 3=level 3; 4=level 4
715-217 Undercolor removal level for color scan 0 0~4 0=std. background suppression; 1=level 1; 2=level 2; 3=level 3; 4=level 4
715-218 Gamma Data for BW 1 0~2 AE GAMMA Data in B/W mode 0=GMD 2; 1=GMD 3; 2=GMD 5
715-219 Gamma Data for Color 1 0~2 AE GAMMA Data in Color mode 0=GMD 2; 1=GMD 3; 2=GMD 5
715-220 Color Balance Default=Y/Low density 4 0~8 Default Color Balance Adjustment Level Y Color Low density
715-221 Color Balance Default=Y/Medium den-
sity
4 0~8 Default Color Balance Adjustment Level Y Color Medium density
715-222 Color Balance Default=Y/High density 4 0~8 Default Color Balance Adjustment Level Y Color High density
715-223 Color Balance Default=M/Low density 4 0~8 Default Color Balance Adjustment Level M Color Low density
715-224 Color Balance Default=M/Medium den-
sity
4 0~8 Default Color Balance Adjustment Level M Color Medium density
715-225 Color Balance Default=M/High density 4 0~8 Default Color Balance Adjustment Level M Color High density
715-226 Color Balance Default=C/Low density 4 0~8 Default Color Balance Adjustment Level C Color Low density
715-227 Color Balance Default=C/Medium den-
sity
4 0~8 Default Color Balance Adjustment Level C Color Medium density
715-228 Color Balance Default=C/High density 4 0~8 Default Color Balance Adjustment Level C Color High density
715-229 Color Balance Default=K/Low density 4 0~8 Default Color Balance Adjustment Level K Color Low density
715-230 Color Balance Default=K/Medium den-
sity
4 0~8 Default Color Balance Adjustment Level K Color Medium density
715-231 Color Balance Default=K/high density 4 0~8 Default Color Balance Adjustment Level K Color High density
715-232 Photo reproduction level 1 0~2 0=Above Text; 1=Normal; 2=Above Photo
715-233 Text/Photo separation level 2 0~4 0=Above Text; 1=Slightly above text; 2=Normal; 3=Slightly above photo; 4=Above Photo
715-234 FS Magnification Adjustment 50 0~100 Magnification fine adjustment in Fast Scan direction. Specified in units between range of 0~100. The value indi-
cates the magnification adjustment with 0=-5%; 50=0% and 100=5% at ±5% (0.1% unit) (Adjustment at factory.)
715-237 Normal Density Text (BW Copy) 128 0~256 B/W COPY Text Normal Density Adjustment
715-238 High Density Text (BW Copy) 128 0~256 B/W COPY Text Darker 3 Density Adjustment
715-239 Normal Density Text (Scan) 128 0~256 Scan Text Normal Density Adjustment
715-240 High Density Text (Scan) 128 0~256 Scan Text Darker 3 Density Adjustment
715-241 SS Not Detect Area for Platen model
(Real Time AE)
38 0~65535 Slow Scan Non-detection area Setup value at Real Time AE for platen model.
715-242 SS Not Detect Area for DADF model
DADF mode (Real Time AE)
38 0~65535 Slow Scan Non-detection area Setup value at Real Time AE for DADF model platen job.
715-243 SS Not Detect Area for DADF model
Platen mode (Real Time AE)
38 0~65535 Slow Scan Non-detection area Setup value at Real Time AE for DADF model DADF job.
715-244 B/W-Offset for Text/Image Platen mode
(Real Time AE)
10 0~255 For AE offset data Platen text/photo in B/W model
715-245 B/W-Offset for Text Platen mode (Real
Time AE)
10 0~255 For AE offset data Platen text in B/W model
715-246 B/W-Offset for Map Platen mode (Real
Time AE)
10 0~255 For AE offset data Platen map in B/W model
Table 1 Chain 715
Chain-Link Name Default Range Description

Xerox DocuColor 2240 Specifications

General

Brand	Xerox
Model	DocuColor 2240
Category	All in One Printer
Language	English
