Xerox DocuColor 2240 Service Manual

09/03
6-63
DC 3535/2240/1632, WC M24
762-xxx Developer NVM List
General Procedures and Information
Initial issue
762-xxx Developer NVM List
Table 1 Chain 762
Chain-Link Name Default Range Description
762-002 #YMC Normal VM1 value 351 0~1023
(1bit=-0.684V)
Vm1 Developer DC energized voltage at YMC Color/Normal speed (104mm/sec.)
762-008 #YM_DB AC Normal Vp-p value 600 0~1023
(1bit=1.491Vpp)
AC peak to peak energized voltage at YM Color/Normal speed.
762-009 #YM_DB AC Normal monitor value 0 0~1023
(1bit=1.491Vpp)
AC applied voltage monitor value at YM Color/Normal speed.
762-012 #K_DB DC Normal Vm1 value 351 0~1023
(1bit=-0.684V)
Vm1 Developer DC energized voltage at K Color/Normal speed (104mm/sec.)
762-013 #CK_DB AC Normal Vp-p value 600 0~1023
(1bit=1.491Vpp)
AC peak to peak energized voltage at CK Color/Normal speed.
762-014 CK_DB AC Normal monitor value 0 0~1023
(1bit=1.491Vpp)
AC applied voltage monitor value at CK Color/Normal speed.
762-015 AC Bias Normal target value 818 0~1023
(1bit=1.491Vpp)
AC target value for Normal speed.
762-018 #YMC_DB DC Half-speed Vm1 value 351 0~1023
(1bit=-0.684V)
Vm1 Developer DC energized voltage at YMC Color/Half speed (52mm/sec.)
762-024 #YM_DB AC Half-speed Vp-p value 600 0~1023
(1bit=1.491Vpp)
AC peak to peak energized voltage at YM Color/Half speed.
762-028 #K_DB DC Half-speed Vm1 value 351 0~1023
(1bit=-0.684V)
Vm1 Developer DC energized voltage at K Color/Half speed (52mm/sec.)
762-029 #CK_DB AC Half-speed Vp-p value 600 0~1023
(1bit=1.491Vpp)
AC peak to peak energized voltage at CK Color/Half speed.
762-040 Recovery DB Normal output value 818 0~1023
(1bit=-0.684V)
Dev Bias applied ref. value during recovery operation - Normal speed.
762-041 Recovery DB half-speed output value 818 0~1023
(1bit=-0.684V)
Dev Bias applied ref. value during recovery operation - half speed.
762-042 Total Drum rotations - YMC 0 0~65535 Total Drum rotations - YMC
762-043 Pixel/Drum rotation threshold for Deve-
Band
20 0~65535 reference value (cumulative no. of pixels/total drum rotations) for creation of DeveBand; 0=No Dev band
762-044 cumulative ICDC_Band_Value_Y 0 0~409600 Y Color cumulative Pixels
762-045 cumulative ICDC_Band_Value_M 0 0~409600 M Color cumulative Pixels
762-046 cumulative ICDC_Band_Value_C 0 0~409600 C Color cumulative Pixels
762-047 cumulative ICDC_Band_Value_K 0 0~409600 K Color cumulative Pixels
762-052 #YM_DB AC Normal test value 0 0~100 AC Voltage test value for YM Color Normal Speed
762-053 #YM_DB AC Normal Frequency 59 0~127 AC Energized Voltage Frequency for YM Color Normal Speed
762-054 #YM_DB AC Normal Output Phase
value
65 0~127 AC Energized Voltage Phase Value at YM Color Normal Speed
762-058 #CK_DB AC Normal test value 0 0~100 AC Voltage test value for CK Color Normal Speed
762-059 #CK_DB AC Normal Frequency 59 0~127 AC Energized Voltage Frequency at CK Color Normal Speed
762-060 #CK_DB AC Normal Output Phase
value
65 0~127 AC Energized Voltage Phase Value at CK Color Normal Speed
