09/03
6-65
DC 3535/2240/1632, WC M24
762-xxx Developer NVM List
General Procedures and Information
Initial issue
762-102 #M_DB DC Vm1 Off half speed timing 92 0~255 Fall timing from Vm1 to Vm0 for M Color half speed. (1bit=4.8924 msec.)
762-103 #C_DB DC Vm1 Off half speed timing 92 0~255 Fall timing from Vm1 to Vm0 for C Color half speed. (1bit=4.8924 msec.)
762-104 #K_DB DC Vm1 Off half speed timing 92 0~255 Fall timing from Vm1 to Vm0 for K Color half speed. (1bit=4.8924 msec.)
762-105 #Y_DB DC VB1 On half-speed timing 104 0~255 Rise timing from Vm1 to VB1 for Y Color Half Speed. (1bit=4.8924 msec.)
762-106 #M_DB DC VB1 On half-speed timing 104 0~255 Rise timing from Vm1 to VB1 for M Color Half Speed. (1bit=4.8924 msec.)
762-107 #C_DB DC VB1 On half-speed timing 104 0~255 Rise timing from Vm1 to VB1 for C Color Half Speed. (1bit=4.8924 msec.)
762-108 #K_DB DC VB1 On half-speed timing 94 0~255 Rise timing from Vm1 to VB1 for K Color Half Speed. (1bit=4.8924 msec.)
762-113 #Y_DB DC VB Off half-speed timing 92 0~255 Fall timing from VB to VB2 for Y Color Half Speed. (1bit=4.8924 msec.)
762-114 #M_DB DC VB Off half-speed timing 92 0~255 Fall timing from VB to VB2 for M Color Half Speed. (1bit=4.8924 msec.)
762-115 #C_DB DC VB Off half-speed timing 92 0~255 Fall timing from VB to VB2 for C Color Half Speed. (1bit=4.8924 msec.)
762-116 #K_DB DC VB Off half-speed timing 88 0~255 Fall timing from VB to VB2 for K Color Half Speed. (1bit=4.8924 msec.)
762-117 #YM_ DB AC On half-speed timing 110 0~255 AC Voltage Energized timing for YM Color Half Speed. (1bit=4.8924 msec.)
762-118 #CK_ DB AC On half-speed timing 110 0~255 AC Voltage Energized timing for CK Color Half Speed. (1bit=4.8924 msec.)
762-119 #YM_ DB AC Off half-speed timing 108 0~255 AC Voltage off timing for YM Color Half Speed. (1bit=4.8924 msec.)
762-120 #CK_ DB AC Off half-speed timing 108 0~255 AC Voltage off timing for CK Color Half Speed. (1bit=4.8924 msec.)
762-121 #YMC_Dev MOT On Normal Timing 184 0~255 Color Developer during motor rising timing for Normal Speed. (1bit=2.4462 msec.)
762-122 #YMC_Dev MOT Off Normal Timing 303 0~1023 Color Developer during motor falling timing for Normal Speed. (1bit=2.4462 msec.)
762-123 #YMC_Dev MOT On half-speed timing 184 0~255 Color Developer during motor rising timing for Half Speed.(1bit=4.8924 msec.)
762-124 #YMC_Dev MOT Off half-speed timing 303 0~1023 Color Developer during motor falling timing for Half Speed. (1bit=4.8924 msec.)
762-125 Recovery DB normal On time 159 0~255 Rise time for Dev Bias during recovery operation - normal speed. (1bit=2.4462 msec.)
762-126 Recovery DB half-speed On time 159 0~255 Rise time for Dev Bias during recovery operation - half speed. (1bit=2.4462 msec.)
762-134 #K_Deve C/L On Normal Timing 164 0~255 K Color Developer during clutch rising timing for Normal Speed. (1bit=2.4462 msec.)
762-135 #K_Deve C/L Off Normal Timing 531 0~1023 K Color Developer during clutch falling timing for Normal Speed. (1bit=2.4462 msec.)
762-136 #K_Deve C/L On half-speed timing 164 0~255 K Color Developer during clutch rising timing for Half Speed. (1bit=4.8924 msec.)
762-137 #K_Deve C/L Off half-speed timing 531 0~1023 K Color Developer during clutch falling timing for Half Speed. (1bit=4.8924 msec.)
762-148 Total Drum rotations_K 0 0~65535 Total number of Black Drum rotations.
762-219 toner_band_width_YMC 10 0~30 Xero/Deve band width (mm) Setup value for YMC Color
762-220 toner_band_width_K 10 0~30 Xero/Deve band width (mm) Setup value for K Color
762-221 toner_band_density_Half-speed_YMC 153 0~255 Half Speed Xero/Deve band density setup value at YMC Color (1bit=0.3922%)
762-222 toner_band_density_Half-speed_K 153 0~255 Half Speed Xero/Deve band density setup value at K Color (1bit=0.3922%)
762-223 toner_band_density_Normal_YMC 153 0~255 Normal Speed Xero/Deve band density setup value at YMC Color (1bit=0.3922%)
762-224 toner_band_density_Normal_K 153 0~255 Normal Speed Xero/Deve band density setup value at K Color (1bit=0.3922%)
762-225 toner_band_density_Hi-speed_YMC 51 0~255 High Speed Xero/Deve band density setup value at YMC Color (1bit=0.3922%)
762-226 toner_band_density_Hi-speed_K 153 0~255 High Speed Xero/Deve band density setup value at K Color (1bit=0.3922%)
762-228 #YM_DB AC Hi-speed Vp-p Value 600 0~1023 AC peak to peak energized voltage at YM Color High Speed. (1bit=0.3922%)
762-229 #CK_DB AC Hi-speed Vp-p Value 600 0~1023
(1bit=1.491Vpp)
AC peak to peak energized voltage at CK Color High Speed.
762-230 Recovery DB increased-speed output 600 0~1023 Reference value for Dev. Bias during recovery operation at increased speed. (1bit=-0.684V)
762-231 #YM_DB AC Hi-speed Frequency * 0~127 AC energized voltage frequency at YM Color High Speed.
* Default=63 for DC 2240/1632; 59 for DC 3535
Table 1 Chain 762
Chain-Link Name Default Range Description
