Xerox DocuColor 2240

09/03
6-76
DC 3535/2240/1632, WC M24
790-xxx ESS Panel Display Setting NVM List
Initial issue
General Procedures and Information
790-132 Fixed Size 2 of Copy Document Size
Input
15 1~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
790-133 Fixed Size 3 of Copy Document Size
Input
18 1~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
790-134 Fixed Size 4 of Copy Document Size
Input
17 1~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
790-135 Fixed Size 5 of Copy Document Size
Input
20 1~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
790-136 Fixed Size 6 of Copy Document Size
Input
22 1~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
790-137 Fixed Size 7 of Copy Document Size
Input
11 1~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
790-138 Fixed Size 8 of Copy Document Size
Input
10 1~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
790-139 Fixed Size 9 of Copy Document Size
Input
13 1~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
790-140 Fixed Size 10 of Copy Document Size
Input
27 1~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
Table 1 Chain 790
Chain-Link Name Default Range Description
