09/03
6-77
DC 3535/2240/1632, WC M24
790-xxx ESS Panel Display Setting NVM List
General Procedures and Information
Initial issue
790-141 Fixed Size 11 of Copy Document Size
Input
28 1~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
790-180 Default Document Orientation in Copy
Mode
0 0~1 0=Head to Top; 1=Head to Left
790-181 Duplex feature default setting 0 0~3 0=Off (1 to 1 Sided); 1=1 to 2 Sided; 2=2 to 1 Sided; 3=2 to 2 Sided
790-182 Default Collate Mode in Copy Mode 0 0~2 0=Auto; 1=Collated; 2=Uncollated
790-183 Default Output Tray in Copy Mode 0 0~2 0=Center Tray 1=Side Tray 2=Finisher Tray * Options that are not installed cannot be selected.
790-184 FAX Sending Display Availability 0 0~1 0 = Off; 1 = On
Receiver Initial Display Availability 0 0~1 0 = Off; 1 = On
790-186 Fax Default Communication Mode 2 0~6 1=G4 Auto; 2=G3 Auto; 3=International Communication (Communication Speed is below 4800bps) 4=G3 5=G3
(ECM) 6=G3 (ECM) - Forced4800
790-187 Default Density (Scan Density) 3 0~6 0=Lighter 3; 1=Lighter 2; 2=Lighter 1; 3=Normal; 4=Darker 1; 5=Darker 2; 6=Darker 3
790-188 Default Image Quality (Document Type) 0 0~2 0=Text; 1=Photo; 2=Text/Photo
790-189 Default Resolution (Scan Resolution) 0 0~3 0=Normal; 1=High Quality (200x200); 2=High Quality (400x400); 3=High Quality (600x600)
790-190 Default Monitor Print 0 0~1 0=Off; 1=On
790-192 Default Sender Records 1 0~1 0=Off; 1=On
790-193 Default display starting number of
Receiver List
1 1~500 1~500
790-194 Default Mixed Size 0 0~1 0=Off; 1=On
790-195 Default Receive Mode 0 0~1 0=Auto Receive; 1=Manual Receive
790-196 Delayed Send Time Setting-Hour 0 0~23 1 bit/hour
790-197 Delayed Send Time Setting-Minutes 0 0~59 1 bit/minute
790-200 Default 1 Setting of Fax Fixed Magnifi-
cation
31~18;
50~400
1=25.0; 2=35.3; 3=50.0; 4=57.7; 5=61.2 6=64.7; 7=70.7; 8=81.6; 9=86.6 10=115.4; 11=122.5; 12=129.4
13=141.4; 14=163.2; 15=173.2 16=200.0; 17=282.8; 18=400.0%; 50~400 incremental - 1 bit = 1%
790-201 Default 2 Setting of Fax Fixed Magnifi-
cation
71~18;
50~400
1=25.0; 2=35.3; 3=50.0; 4=57.7; 5=61.2 6=64.7; 7=70.7; 8=81.6; 9=86.6 10=115.4; 11=122.5; 12=129.4
13=141.4; 14=163.2; 15=173.2 16=200.0; 17=282.8; 18=400.0%; 50~400 incremental - 1 bit = 1%
790-202 Default 3 Setting of Fax Fixed Magnifi-
cation
81~18;
50~400
1=25.0; 2=35.3; 3=50.0; 4=57.7; 5=61.2 6=64.7; 7=70.7; 8=81.6; 9=86.6 10=115.4; 11=122.5; 12=129.4
13=141.4; 14=163.2; 15=173.2 16=200.0; 17=282.8; 18=400.0%; 50~400 incremental - 1 bit = 1%
790-203 Default 4 Setting of Fax Fixed Magnifi-
cation
91~18;
50~400
1=25.0; 2=35.3; 3=50.0; 4=57.7; 5=61.2 6=64.7; 7=70.7; 8=81.6; 9=86.6 10=115.4; 11=122.5; 12=129.4
13=141.4; 14=163.2; 15=173.2 16=200.0; 17=282.8; 18=400.0%; 50~400 incremental - 1 bit = 1%
790-204 Default 5 Setting of Fax Fixed Magnifi-
cation
10 1~18;
50~400
1=25.0; 2=35.3; 3=50.0; 4=57.7; 5=61.2 6=64.7; 7=70.7; 8=81.6; 9=86.6 10=115.4; 11=122.5; 12=129.4
13=141.4; 14=163.2; 15=173.2 16=200.0; 17=282.8; 18=400.0%; 50~400 incremental - 1 bit = 1%
790-205 Default 6 Setting of Fax Fixed Magnifi-
cation
11 1~18;
50~400
1=25.0; 2=35.3; 3=50.0; 4=57.7; 5=61.2 6=64.7; 7=70.7; 8=81.6; 9=86.6 10=115.4; 11=122.5; 12=129.4
13=141.4; 14=163.2; 15=173.2 16=200.0; 17=282.8; 18=400.0%; 50~400 incremental - 1 bit = 1%
790-206 Default 7 Setting of Fax Fixed Magnifi-
cation
13 1~18;
50~400
1=25.0; 2=35.3; 3=50.0; 4=57.7; 5=61.2 6=64.7; 7=70.7; 8=81.6; 9=86.6 10=115.4; 11=122.5; 12=129.4
13=141.4; 14=163.2; 15=173.2 16=200.0; 17=282.8; 18=400.0%; 50~400 incremental - 1 bit = 1%
790-210 Fixed Size 1 of Fax Scan Size Input 13 1~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
Table 1 Chain 790
Chain-Link Name Default Range Description
