Xerox DocuColor 2240

09/03
6-78
DC 3535/2240/1632, WC M24
790-xxx ESS Panel Display Setting NVM List
Initial issue
General Procedures and Information
790-211 Fixed Size 2 of Fax Scan Size Input 10 1~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
790-212 Fixed Size 3 of Fax Scan Size Input 11 1~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
790-213 Fixed Size 4 of Fax Scan Size Input 7 1~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
790-214 Fixed Size 5 of Fax Scan Size Input 12 1~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
790-215 Fixed Size 6 of Fax Scan Size Input 8 1~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
790-216 Fixed Size 7 of Fax Scan Size Input 9 1~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
790-217 Fixed Size 8 of Fax Scan Size Input 22 1~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
790-218 Fixed Size 9 of Fax Scan Size Input 20 1~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
790-219 Fixed Size 10 of Fax Scan Size Input 17 1~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
Table 1 Chain 790
Chain-Link Name Default Range Description
