790-xxx ESS Panel Display Setting NVM List
General Procedures and Information
Initial issue
790-220 Fixed Size 11 of Fax Scan Size Input 18 1~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
790-221 Default FAX Profile 0 0~2 0 = TIFF-S, 1 = TIFF-F, 2 = TIFF-J
790-222 Default Mixed Size 0 0~1 0=Off; 1=On
790-223 Default Color Mode * 0~3 0=Full Color; 1=Grey Color; 2=B/W Binary; 3=Auto
*Default is 3 for DC 2240/1632WC24; 0 for DC 3535
790-224 Default Document Type 1 0~2 0=Text; 1=Text/Photo; 2=Photo
790-225 Default Resolution 0 0~3 0=200dpi; 1=300dpi; 2=400dpi; 3=600dpi
790-226 Default Top and Bottom Edge Erase 2 0~50 0~50; increments of 1mm
790-227 Default Left and Right Edge Erase 2 0~50 0~50; increments of 1mm
790-228 Default Center Erase 0 0~50 0~50; increments of 1mm
790-229 Default Density/Brightness Adjustment
(Using data common to Density; Bright-
ness)
3 0~6 0=Brightness (Density) 3; 1=Brightness (Density) 2; 2=Brightness (Density) 1; 3=Normal; 4=Brightness (Den-
sity) -1; 5=Brightness (Density) -2; 6=Brightness (Density) -3
790-230 Default Contrast Adjustment 2 0~4 0=Stronger 2; 1=Stronger 1; 2=Normal; 3=Softer 1; 4=Softer 2
790-231 Fixed Size 1 of Scan Document Size
Input
16 1~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
790-232 Fixed Size 2 of Scan Document Size
Input
15 1~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
790-233 Fixed Size 3 of Scan Document Size
Input
18 1~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
790-234 Fixed Size 4 of Scan Document Size
Input
17 1~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
790-235 Fixed Size 5 of Scan Document Size
Input
20 1~50 1=Postcard; 2=A6SEF; 3=A6LEF; 4=B6SEF; 5=B6LEF; 6=A5SEF; 7=A5LEF; 8=B5SEF; 9=B5LEF; 10=A4SEF;
11=A4LEF; 12=B4SEF; 13=A3SEF; 14=Postcard (4x6); 15=5.5x8.5SEF; 16=5.5x8.5LEF; 17=8.5x11SEF;
18=8.5x11LEF;19=8.5x13SEF; 20=8.5x14; 21=11x15SEF; 22=11x17SEF; 23=AP Envelope (Cho-3 gou);
24=8-K SEF; 25=16-K SEF; 26=16-K LEF; 27=3.5×5 (Photo L size); 28=5×7(Photo 2L size); 29=#10 Envelope
LEF; 31=8×10SEF; 40~50=Non-standard size for each button
Table 1 Chain 790
Chain-Link Name Default Range Description
