DC 3535/2240/1632, WC M24
825-xxx ESS Fax Service Protocol Setting NVM
General Procedures and Information
Initial issue
825-054 PB Send Level (high-pass - low-pass
(dB)) For Ch2
0 0~15 0=2.0; 1=2.5; 2=3.0; 3=3.5; 4=4.0; 5=4.5; 6=5.0; 7=5.5; 8=-2.0; 9=-1.5; 10=-1.0; 11=-0.5; 12=0; 13=0.5;14=1.0;
15=1.5
825-055 PB Send Level (high-pass - low-pass
(dB)) For Ch3
0 0~15 0=2.0; 1=2.5; 2=3.0; 3=3.5; 4=4.0; 5=4.5; 6=5.0; 7=5.5; 8=-2.0; 9=-1.5; 10=-1.0; 11=-0.5; 12=0; 13=0.5;14=1.0;
15=1.5
825-056 PB Send Level (high-pass - low-pass
(dB)) For Ch4
0 0~15 0=2.0; 1=2.5; 2=3.0; 3=3.5; 4=4.0; 5=4.5; 6=5.0; 7=5.5; 8=-2.0; 9=-1.5; 10=-1.0; 11=-0.5; 12=0; 13=0.5;14=1.0;
15=1.5
825-057 PB Send Level (high-pass - low-pass
(dB)) For Ch5
0 0~15 0=2.0; 1=2.5; 2=3.0; 3=3.5; 4=4.0; 5=4.5; 6=5.0; 7=5.5; 8=-2.0; 9=-1.5; 10=-1.0; 11=-0.5; 12=0; 13=0.5;14=1.0;
15=1.5
825-058 Busy Tone detection before dialing For
Ch0
0 0~1 0= Busy Tone detection Off; 1= Busy Tone detection On
825-059 Busy Tone detection before dialing For
Ch1
0 0~1 0= Busy Tone detection Off; 1= Busy Tone detection On
825-060 Busy Tone detection before dialing For
Ch2
0 0~1 0= Busy Tone detection Off; 1= Busy Tone detection On
825-061 Busy Tone detection before dialing For
Ch3
0 0~1 0= Busy Tone detection Off; 1= Busy Tone detection On
825-062 Busy Tone detection before dialing For
Ch4
0 0~1 0= Busy Tone detection Off; 1= Busy Tone detection On
825-063 Busy Tone detection before dialing For
Ch5
0 0~1 0= Busy Tone detection Off; 1= Busy Tone detection On
825-064 Dial Tone detection before dialing For
Ch0
1 0~1 0= Dial Tone detection Off; 1= Dial Tone detection On
825-065 Dial Tone detection before dialing For
Ch1
1 0~1 0= Dial Tone detection Off; 1= Dial Tone detection On
825-066 Dial Tone detection before dialing For
Ch2
1 0~1 0= Dial Tone detection Off; 1= Dial Tone detection On
825-067 Dial Tone detection before dialing For
Ch3
1 0~1 0= Dial Tone detection Off; 1= Dial Tone detection On
825-068 Dial Tone detection before dialing For
Ch4
1 0~1 0= Dial Tone detection Off; 1= Dial Tone detection On
825-069 Dial Tone detection before dialing For
Ch5
1 0~1 0= Dial Tone detection Off; 1= Dial Tone detection On
825-070 Dial Tone detection before dialing
(PBX)
0 0~1 0= Dial Tone detection Off; 1= Dial Tone detection On
825-071 Timing of tone detection before dialing
For Ch0
4 0~255 0 ~ 255 (Sec)
825-072 Timing of tone detection before dialing
For Ch1
10 0~255 0 ~ 255 (Sec)
825-073 Timing of tone detection before dialing
For Ch2
10 0~255 0 ~ 255 (Sec)
825-074 Timing of tone detection before dialing
For Ch3
10 0~255 0 ~ 255 (Sec)
825-075 Timing of tone detection before dialing
For Ch4
10 0~255 0 ~ 255 (Sec)
Table 1 Chain 825
Chain/Link Name Default Range Description
To Next Page
