Xerox DocuColor 2240 Service Manual

09/03
6-97
DC 3535/2240/1632, WC M24
825-xxx ESS Fax Service Protocol Setting NVM
General Procedures and Information
Initial issue
825-261 G3 TSI/CIG Send TSI for Ch4 0 0~255 0 = Auto; 1 = Forced Transmit; 10 = Not Transmit. Notification signal of the Sender ID by the signal for the CSI
signal from the recipient. CIG = Indicates recognition information of the call station.
825-262 G3 TSI/CIG Send TSI for Ch5 0 0~255 0 = Auto; 1 = Forced Transmit; 10 = Not Transmit. Notification signal of the Sender ID by the signal for the CSI
signal from the recipient. CIG = Indicates recognition information of the call station.
825-263 G3 TX Cable Equalizer for Ch0 1 - 0=0dB; 1=4dB; 2=8dB; 3=12dB
825-264 G3 TX Cable Equalizer for Ch1 1 - 0=0dB; 1=4dB; 2=8dB; 3=12dB
825-265 G3 TX Cable Equalizer for Ch2 1 - 0=0dB; 1=4dB; 2=8dB; 3=12dB
825-266 G3 TX Cable Equalizer for Ch3 1 - 0=0dB; 1=4dB; 2=8dB; 3=12dB
825-267 G3 TX Cable Equalizer for Ch4 1 - 0=0dB; 1=4dB; 2=8dB; 3=12dB
825-268 G3 TX Cable Equalizer for Ch5 1 - 0=0dB; 1=4dB; 2=8dB; 3=12dB
825-274 Line Error Value setting 0 - 0= No limit. 1= 128 lines; 2= 256 lines; 3= 512 lines; 4= 1024 lines; 5= 2048 line.
RTN is sent if error Line is 1/2 or above the value set. RTN is sent if error Line is 1/4 or above the value set.
MCF is sent if error Line is less 1/4 of the value set.
825-275 Reference for when RTN is sent. 0 - 0= Proportional; 1= No. of Lines
825-276 Incoming Tone Detection Level for Ch0 1 - 0=-48dBm; 1=-43dBm; 2=-38dBm; 3=-33dBm
825-277 Incoming Tone Detection Level for Ch1 1 - 0=-48dBm; 1=-43dBm; 2=-38dBm; 3=-33dBm
825-278 Incoming Tone Detection Level for Ch2 1 - 0=-48dBm; 1=-43dBm; 2=-38dBm; 3=-33dBm
825-279 Incoming Tone Detection Level for Ch3 1 - 0=-48dBm; 1=-43dBm; 2=-38dBm; 3=-33dBm
825-280 Incoming Tone Detection Level for Ch4 1 - 0=-48dBm; 1=-43dBm; 2=-38dBm; 3=-33dBm
825-281 Incoming Tone Detection Level for Ch5 1 - 0=-48dBm; 1=-43dBm; 2=-38dBm; 3=-33dBm
825-285 Transmission Paper Size 0x014c - 0x0000 0002=A3; 0x0000 0004=A4; 0x0000 0020=B4; 0x0000 0100=Letter; 0x0000 0200=Legal; 0x0000
0400=Ledger; 0x0000 0800=8.5x13 inch; 0x0004 0000=A4LEF; 0x0008 0000=A5LEF; 0x0040 0000=B5LEF;
0x0100 0000=Letter LEF; 0x0200 0000=Letter Half LEF
0726 = A3, A4, B4, A4LEF, A5LEF, B5LEF, Letter, Legal, Ledger, Letter LEF
825-322 Set V34 modulation method enable. 1 0~1 0=Disable, 1=Enable
Table 1 Chain 825
Chain/Link Name Default Range Description
