Xerox DocuColor 2240 Service Manual

09/03
6-96
DC 3535/2240/1632, WC M24
825-xxx ESS Fax Service Protocol Setting NVM List
Initial issue
General Procedures and Information
825-241 G3 Modem TX Communication Speed
Capability (V.34) for Channel 2
14 1~14 14 = 33600 bps (1110); 31200 bps (1101); 28800 bps (1100); 26400 bps (1011); 24000 bps (1010); 21600 bps
(1001); 19200 bps (1000); 16800 bps (0111); 14400 bps (0110); 12000 bps (0101); 9600 bps (0100); 7200 bps
(0011); 4800 bps (0010); 2400 bps (0001)
825-242 G3 Modem TX Communication Speed
Capability (V.34) for Channel 3
14 1~14 14 = 33600 bps (1110); 31200 bps (1101); 28800 bps (1100); 26400 bps (1011); 24000 bps (1010); 21600 bps
(1001); 19200 bps (1000); 16800 bps (0111); 14400 bps (0110); 12000 bps (0101); 9600 bps (0100); 7200 bps
(0011); 4800 bps (0010); 2400 bps (0001)
825-243 G3 Modem TX Communication Speed
Capability (V.34) for Channel 4
14 1~14 14 = 33600 bps (1110); 31200 bps (1101); 28800 bps (1100); 26400 bps (1011); 24000 bps (1010); 21600 bps
(1001); 19200 bps (1000); 16800 bps (0111); 14400 bps (0110); 12000 bps (0101); 9600 bps (0100); 7200 bps
(0011); 4800 bps (0010); 2400 bps (0001)
825-244 G3 Modem TX Communication Speed
Capability (V.34) for Channel 5
14 1~14 14 = 33600 bps (1110); 31200 bps (1101); 28800 bps (1100); 26400 bps (1011); 24000 bps (1010); 21600 bps
(1001); 19200 bps (1000); 16800 bps (0111); 14400 bps (0110); 12000 bps (0101); 9600 bps (0100); 7200 bps
(0011); 4800 bps (0010); 2400 bps (0001)
825-245 G3 Modem TX Communication Speed
Capability (V.34 - overseas communi-
cation) - Ch0
14 1~14 14 = 33600 bps (1110); 31200 bps (1101); 28800 bps (1100); 26400 bps (1011); 24000 bps (1010); 21600 bps
(1001); 19200 bps (1000); 16800 bps (0111); 14400 bps (0110); 12000 bps (0101); 9600 bps (0100); 7200 bps
(0011); 4800 bps (0010); 2400 bps (0001)
825-246 G3 Modem TX Communication Speed
Capability (V.34 - overseas communi-
cation) - Ch1
14 1~14 14 = 33600 bps (1110); 31200 bps (1101); 28800 bps (1100); 26400 bps (1011); 24000 bps (1010); 21600 bps
(1001); 19200 bps (1000); 16800 bps (0111); 14400 bps (0110); 12000 bps (0101); 9600 bps (0100); 7200 bps
(0011); 4800 bps (0010); 2400 bps (0001)
825-247 G3 Modem TX Communication Speed
Capability (V.34 - overseas communi-
cation) - Ch2
14 1~14 14 = 33600 bps (1110); 31200 bps (1101); 28800 bps (1100); 26400 bps (1011); 24000 bps (1010); 21600 bps
(1001); 19200 bps (1000); 16800 bps (0111); 14400 bps (0110); 12000 bps (0101); 9600 bps (0100); 7200 bps
(0011); 4800 bps (0010); 2400 bps (0001)
825-248 G3 Modem TX Communication Speed
Capability (V.34 - overseas communi-
cation) - Ch3
14 1~14 14 = 33600 bps (1110); 31200 bps (1101); 28800 bps (1100); 26400 bps (1011); 24000 bps (1010); 21600 bps
(1001); 19200 bps (1000); 16800 bps (0111); 14400 bps (0110); 12000 bps (0101); 9600 bps (0100); 7200 bps
(0011); 4800 bps (0010); 2400 bps (0001)
825-249 G3 Modem TX Communication Speed
Capability (V.34 - overseas communi-
cation) - Ch4
14 1~14 14 = 33600 bps (1110); 31200 bps (1101); 28800 bps (1100); 26400 bps (1011); 24000 bps (1010); 21600 bps
(1001); 19200 bps (1000); 16800 bps (0111); 14400 bps (0110); 12000 bps (0101); 9600 bps (0100); 7200 bps
(0011); 4800 bps (0010); 2400 bps (0001)
825-250 G3 Modem TX Communication Speed
Capability (V.34 - overseas communi-
cation) - Ch5
14 1~14 14 = 33600 bps (1110); 31200 bps (1101); 28800 bps (1100); 26400 bps (1011); 24000 bps (1010); 21600 bps
(1001); 19200 bps (1000); 16800 bps (0111); 14400 bps (0110); 12000 bps (0101); 9600 bps (0100); 7200 bps
(0011); 4800 bps (0010); 2400 bps (0001)
825-251 G3 RX Cable Equalizer for Channel 0 1 - 0=0dB; 1=4dB; 2=8dB; 3=12dB
825-252 G3 RX Cable Equalizer for Channel 1 1 - 0=0dB; 1=4dB; 2=8dB; 3=12dB
825-253 G3 RX Cable Equalizer for Channel 2 1 - 0=0dB; 1=4dB; 2=8dB; 3=12dB
825-254 G3 RX Cable Equalizer for Channel 3 1 - 0=0dB; 1=4dB; 2=8dB; 3=12dB
825-255 G3 RX Cable Equalizer for Channel 4 1 - 0=0dB; 1=4dB; 2=8dB; 3=12dB
825-256 G3 RX Cable Equalizer for Channel 5 1 - 0=0dB; 1=4dB; 2=8dB; 3=12dB
825-257 G3 TSI/CIG Send TSI for Ch0 0 0~255 0 = Auto; 1 = Forced Transmit; 10 = Not Transmit. Notification signal of the Sender ID by the signal for the CSI
signal from the recipient. CIG = Indicates recognition information of the call station.
825-258 G3 TSI/CIG Send TSI for Ch1 0 0~255 0 = Auto; 1 = Forced Transmit; 10 = Not Transmit. Notification signal of the Sender ID by the signal for the CSI
signal from the recipient. CIG = Indicates recognition information of the call station.
825-259 G3 TSI/CIG Send TSI for Ch2 0 0~255 0 = Auto; 1 = Forced Transmit; 10 = Not Transmit. Notification signal of the Sender ID by the signal for the CSI
signal from the recipient. CIG = Indicates recognition information of the call station.
825-260 G3 TSI/CIG Send TSI for Ch3 0 0~255 0 = Auto; 1 = Forced Transmit; 10 = Not Transmit. Notification signal of the Sender ID by the signal for the CSI
signal from the recipient. CIG = Indicates recognition information of the call station.
Table 1 Chain 825
Chain/Link Name Default Range Description
