Xerox DocuColor 2240 Service Manual

09/03
6-95
DC 3535/2240/1632, WC M24
825-xxx ESS Fax Service Protocol Setting NVM
General Procedures and Information
Initial issue
825-223 G3 Modem RX Communication Speed
Capability (V.34) for Channel 2
14 1~14 14 = 33600 bps (1110); 31200 bps (1101); 28800 bps (1100); 26400 bps (1011); 24000 bps (1010); 21600 bps
(1001); 19200 bps (1000); 16800 bps (0111); 14400 bps (0110); 12000 bps (0101); 9600 bps (0100); 7200 bps
(0011); 4800 bps (0010); 2400 bps (0001)
825-224 G3 Modem RX Communication Speed
Capability (V.34) for Channel 3
14 1~14 14
825-225 G3 Modem RX Communication Speed
Capability (V.34) for Channel 4
14 1~14 14
825-226 G3 Modem RX Communication Speed
Capability (V.34) for Channel 5
14 1~14 14
825-227 G3 Modem TX Communication Speed
Capability (non-V.34) for Channel 0
8 1~8 8 = 14400 bps/V.17 (1000); 7 = 12000 bps/V.17 (0111); 6 = 9600 bps/V.17 (0110); 5 = 7200 bps/V.17 (0101); 4 =
9600 bps/V.29 (0100); 3 = 7200 bps/V.29 (0011); 2 =4800 bps/V.27ter (0010); 1 = 2400 bps/V.27ter (0001)
825-228 G3 Modem TX Communication Speed
Capability (non-V.34) for Channel 1
8 1~8 8 = 14400 bps/V.17 (1000); 7 = 12000 bps/V.17 (0111); 6 = 9600 bps/V.17 (0110); 5 = 7200 bps/V.17 (0101); 4 =
9600 bps/V.29 (0100); 3 = 7200 bps/V.29 (0011); 2 =4800 bps/V.27ter (0010); 1 = 2400 bps/V.27ter (0001)
825-229 G3 Modem TX Communication Speed
Capability (non-V.34) for Channel 2
8 1~8 8 = 14400 bps/V.17 (1000); 7 = 12000 bps/V.17 (0111); 6 = 9600 bps/V.17 (0110); 5 = 7200 bps/V.17 (0101); 4 =
9600 bps/V.29 (0100); 3 = 7200 bps/V.29 (0011); 2 =4800 bps/V.27ter (0010); 1 = 2400 bps/V.27ter (0001)
825-230 G3 Modem TX Communication Speed
Capability (non-V.34) for Channel 3
8 1~8 8 = 14400 bps/V.17 (1000); 7 = 12000 bps/V.17 (0111); 6 = 9600 bps/V.17 (0110); 5 = 7200 bps/V.17 (0101); 4 =
9600 bps/V.29 (0100); 3 = 7200 bps/V.29 (0011); 2 =4800 bps/V.27ter (0010); 1 = 2400 bps/V.27ter (0001)
825-231 G3 Modem TX Communication Speed
Capability (non-V.34) for Channel 4
8 1~8 8 = 14400 bps/V.17 (1000); 7 = 12000 bps/V.17 (0111); 6 = 9600 bps/V.17 (0110); 5 = 7200 bps/V.17 (0101); 4 =
9600 bps/V.29 (0100); 3 = 7200 bps/V.29 (0011); 2 =4800 bps/V.27ter (0010); 1 = 2400 bps/V.27ter (0001)
825-232 G3 Modem TX Communication Speed
Capability (non-V.34) for Channel 5
8 1~8 8 = 14400 bps/V.17 (1000); 7 = 12000 bps/V.17 (0111); 6 = 9600 bps/V.17 (0110); 5 = 7200 bps/V.17 (0101); 4 =
9600 bps/V.29 (0100); 3 = 7200 bps/V.29 (0011); 2 =4800 bps/V.27ter (0010); 1 = 2400 bps/V.27ter (0001)
825-233 G3 Modem TX Communication Speed
Capability (non-V.34 - overseas com-
munication) for Channel 0
2 1~8 8 = 14400 bps/V.17 (1000); 7 = 12000 bps/V.17 (0111); 6 = 9600 bps/V.17 (0110); 5 = 7200 bps/V.17 (0101); 4 =
9600 bps/V.29 (0100); 3 = 7200 bps/V.29 (0011); 2 =4800 bps/V.27ter (0010); 1 = 2400 bps/V.27ter (0001)
825-234 G3 Modem TX Communication Speed
Capability (non-V.34 - overseas com-
munication) for Channel 1
2 1~8 8 = 14400 bps/V.17 (1000); 7 = 12000 bps/V.17 (0111); 6 = 9600 bps/V.17 (0110); 5 = 7200 bps/V.17 (0101); 4 =
9600 bps/V.29 (0100); 3 = 7200 bps/V.29 (0011); 2 =4800 bps/V.27ter (0010); 1 = 2400 bps/V.27ter (0001)
825-235 G3 Modem TX Communication Speed
Capability (non-V.34 - overseas com-
munication) for Channel 2
2 1~8 8 = 14400 bps/V.17 (1000); 7 = 12000 bps/V.17 (0111); 6 = 9600 bps/V.17 (0110); 5 = 7200 bps/V.17 (0101); 4 =
9600 bps/V.29 (0100); 3 = 7200 bps/V.29 (0011); 2 =4800 bps/V.27ter (0010); 1 = 2400 bps/V.27ter (0001)
825-236 G3 Modem TX Communication Speed
Capability (non-V.34 - overseas com-
munication) for Channel 3
2 1~8 8 = 14400 bps/V.17 (1000); 7 = 12000 bps/V.17 (0111); 6 = 9600 bps/V.17 (0110); 5 = 7200 bps/V.17 (0101); 4 =
9600 bps/V.29 (0100); 3 = 7200 bps/V.29 (0011); 2 =4800 bps/V.27ter (0010); 1 = 2400 bps/V.27ter (0001)
825-237 G3 Modem TX Communication Speed
Capability (non-V.34 - overseas com-
munication) for Channel 4
2 1~8 8 = 14400 bps/V.17 (1000); 7 = 12000 bps/V.17 (0111); 6 = 9600 bps/V.17 (0110); 5 = 7200 bps/V.17 (0101); 4 =
9600 bps/V.29 (0100); 3 = 7200 bps/V.29 (0011); 2 =4800 bps/V.27ter (0010); 1 = 2400 bps/V.27ter (0001)
825-238 G3 Modem TX Communication Speed
Capability (non-V.34 - overseas com-
munication) for Channel 50
2 1~8 8 = 14400 bps/V.17 (1000); 7 = 12000 bps/V.17 (0111); 6 = 9600 bps/V.17 (0110); 5 = 7200 bps/V.17 (0101); 4 =
9600 bps/V.29 (0100); 3 = 7200 bps/V.29 (0011); 2 =4800 bps/V.27ter (0010); 1 = 2400 bps/V.27ter (0001)
825-239 G3 Modem TX Communication Speed
Capability (V.34) for Channel 0
14 1~14 14 = 33600 bps (1110); 31200 bps (1101); 28800 bps (1100); 26400 bps (1011); 24000 bps (1010); 21600 bps
(1001); 19200 bps (1000); 16800 bps (0111); 14400 bps (0110); 12000 bps (0101); 9600 bps (0100); 7200 bps
(0011); 4800 bps (0010); 2400 bps (0001)
825-240 G3 Modem TX Communication Speed
Capability (V.34) for Channel 1
14 1~14 14 = 33600 bps (1110); 31200 bps (1101); 28800 bps (1100); 26400 bps (1011); 24000 bps (1010); 21600 bps
(1001); 19200 bps (1000); 16800 bps (0111); 14400 bps (0110); 12000 bps (0101); 9600 bps (0100); 7200 bps
(0011); 4800 bps (0010); 2400 bps (0001)
Table 1 Chain 825
Chain/Link Name Default Range Description
