Xerox DocuColor 2240

09/03
6-94
DC 3535/2240/1632, WC M24
825-xxx ESS Fax Service Protocol Setting NVM List
Initial issue
General Procedures and Information
825-194 ECM CTC Speed Shift Down for Ch3 1 0~1 0 = No Shift; 1 = Shift Down. (CTC= Instructs to continue resending for the same block and to change the trans-
mission speed as required, by the signal capable of transmission for every 3 resends)
825-195 ECM CTC Speed Shift Down for Ch4 1 0~1 0 = No Shift; 1 = Shift Down. (CTC= Instructs to continue resending for the same block and to change the trans-
mission speed as required, by the signal capable of transmission for every 3 resends)
825-196 ECM CTC Speed Shift Down for Ch5 1 0~1 0 = No Shift; 1 = Shift Down. (CTC= Instructs to continue resending for the same block and to change the trans-
mission speed as required, by the signal capable of transmission for every 3 resends)
825-197 G3 DIS ignore for Channel 0 (No. of
times DIS ignored)
0 - 0= Do not ignore DIS.; 1= DIS ignored once.
825-198 G3 DIS ignore for Channel 1 (No. of
times DIS ignored)
0 - 0= Do not ignore DIS.; 1= DIS ignored once.
825-199 G3 DIS ignore for Channel 2 (No. of
times DIS ignored)
0 - 0= Do not ignore DIS.; 1= DIS ignored once.
825-200 G3 DIS ignore for Channel 3 (No. of
times DIS ignored)
0 - 0= Do not ignore DIS.; 1= DIS ignored once.
825-201 G3 DIS ignore for Channel 4 (No. of
times DIS ignored)
0 - 0= Do not ignore DIS.; 1= DIS ignored once.
825-202 G3 DIS ignore for Channel 5 (No. of
DIS ignored)
0 - 0= Do not ignore DIS.; 1= DIS ignored once.
825-203 G3 ECM EOR_Q Command for Chan-
nel 0
1 - 0= Stop; 1= Continue
825-209 G3 Modem Mode For Ch0 1 - 0= CCITT G3; 1= Auto
825-210 G3 Modem Mode For Ch1 1 - 0= CCITT G3; 1= Auto
825-211 G3 Modem Mode For Ch 2 1 - 0= CCITT G3; 1= Auto
825-212 G3 Modem Mode For Ch 3 1 - 0= CCITT G3; 1= Auto
825-213 G3 Modem Mode For Ch 4 1 - 0= CCITT G3; 1= Auto
825-214 G3 Modem Mode For Ch 5 1 - 0= CCITT G3; 1= Auto
825-215 G3 Modem RX Communication Speed
Capability (non-V.34) for Channel 0
8 1 ~ 8 8 = 14400 bps/V.17 (1000); 7 = 12000 bps/V.17 (0111); 6 = 9600 bps/V.17 (0110); 5 = 7200 bps/V.17 (0101); 4 =
9600 bps/V.29 (0100); 3 = 7200 bps/V.29 (0011); 2 =4800 bps/V.27ter (0010); 1 = 2400 bps/V.27ter (0001)
825-216 G3 Modem RX Communication Speed
Capability (non-V.34) for Channel 1
8 1 ~ 8 8 = 14400 bps/V.17 (1000); 7 = 12000 bps/V.17 (0111); 6 = 9600 bps/V.17 (0110); 5 = 7200 bps/V.17 (0101); 4 =
9600 bps/V.29 (0100); 3 = 7200 bps/V.29 (0011); 2 =4800 bps/V.27ter (0010); 1 = 2400 bps/V.27ter (0001)
825-217 G3 Modem RX Communication Speed
Capability (non-V.34) for Channel 2
8 1 ~ 8 8 = 14400 bps/V.17 (1000); 7 = 12000 bps/V.17 (0111); 6 = 9600 bps/V.17 (0110); 5 = 7200 bps/V.17 (0101); 4 =
9600 bps/V.29 (0100); 3 = 7200 bps/V.29 (0011); 2 =4800 bps/V.27ter (0010); 1 = 2400 bps/V.27ter (0001)
825-218 G3 Modem RX Communication Speed
Capability (non-V.34) for Channel 3
8 1 ~ 8 8 = 14400 bps/V.17 (1000); 7 = 12000 bps/V.17 (0111); 6 = 9600 bps/V.17 (0110); 5 = 7200 bps/V.17 (0101); 4 =
9600 bps/V.29 (0100); 3 = 7200 bps/V.29 (0011); 2 =4800 bps/V.27ter (0010); 1 = 2400 bps/V.27ter (0001)
825-219 G3 Modem RX Communication Speed
Capability (non-V.34) for Channel 4
8 1 ~ 8 8 = 14400 bps/V.17 (1000); 7 = 12000 bps/V.17 (0111); 6 = 9600 bps/V.17 (0110); 5 = 7200 bps/V.17 (0101); 4 =
9600 bps/V.29 (0100); 3 = 7200 bps/V.29 (0011); 2 =4800 bps/V.27ter (0010); 1 = 2400 bps/V.27ter (0001)
825-220 G3 Modem RX Communication Speed
Capability (non-V.34) for Channel 5
8 1 ~ 8 8 = 14400 bps/V.17 (1000); 7 = 12000 bps/V.17 (0111); 6 = 9600 bps/V.17 (0110); 5 = 7200 bps/V.17 (0101); 4 =
9600 bps/V.29 (0100); 3 = 7200 bps/V.29 (0011); 2 =4800 bps/V.27ter (0010); 1 = 2400 bps/V.27ter (0001)
825-221 G3 Modem RX Communication Speed
Capability (V.34) for Channel 0
14 1~14 14 = 33600 bps (1110); 31200 bps (1101); 28800 bps (1100); 26400 bps (1011); 24000 bps (1010); 21600 bps
(1001); 19200 bps (1000); 16800 bps (0111); 14400 bps (0110); 12000 bps (0101); 9600 bps (0100); 7200 bps
(0011); 4800 bps (0010); 2400 bps (0001)
825-222 G3 Modem RX Communication Speed
Capability (V.34) for Channel 1
14 1~14 14 = 33600 bps (1110); 31200 bps (1101); 28800 bps (1100); 26400 bps (1011); 24000 bps (1010); 21600 bps
(1001); 19200 bps (1000); 16800 bps (0111); 14400 bps (0110); 12000 bps (0101); 9600 bps (0100); 7200 bps
(0011); 4800 bps (0010); 2400 bps (0001)
Table 1 Chain 825
Chain/Link Name Default Range Description
