Xerox DocuColor 2240 Service Manual

09/03
6-134
DC 3535/2240/1632, WC M24
Product Specs.
Initial issue
General Procedures and Information
Product Codes
Component Weights
Paper Capacities
Table 1 Product Codes DC 2240/1632
Item Product Code
DocuColor 1632 IOT 120 VAC LVE
DocuColor 1632 IOT 220 VAC LVF
Scanner/UI/DADF (XC) 120 VAC LVM
Scanner/UI/DADF (XE) 220 VAC LVN
Speed Upgrade Kit (1632 to 2240) MDU
Finisher KMT
Token Ring Kit MLH
Left Wing Kit MLG
Foreign Interface Kit NMP
Table 2 Product Codes DC 3535
Item Product Code
DocuColor 3535 IOT 120 VAC LVG
DocuColor 3535 IOT 220 VAC LVH
Scanner/UI/DADF (XC) 120 VAC MWD
Scanner/UI/DADF (XE) 220 VAC MWE
EFI Network Controller MWF
3-Tray Module NKT
Tandem Tray Module NKU
DC 3535 IOT/Network Controller/
3TM - preconfigured
NTW
DC 3535 IOT/Network Controller/
TTM - preconfigured
NTY
Finisher Option KNL
DT-32 Densitometer Option R0E
ED-100 Densitometer Option FVK
Foreign Interface Option NMP
Table 3 Product Codes WC M24
Item Product Code
WorkCentre M24 IOT 120 VAC RLU
WorkCentre M24 IOT 220 VAC RLV
Scanner/UI/DADF (XC) 120 VAC RLY
Scanner/UI/DADF (XE) 220 VAC RMC
Scanner/UI/Platen (XC) 120 VAC RMD
Scanner/UI/Platen (XE) 220 VAC RLW
Cabinet RME
3-Tray Module RMF
Tandem Tray Module RMG
Std. G3 Fax Kit (XC) RMH
Std. G3 Fax Kit (XE) RMK
Convenience Stapler (XC) NPG
Convenience Stapler (XE) NPH
Finisher KMT
Foreign Interface Kit NMP
Table 4 Component Weights
Component Weight (approx.)
IOT w/3TM or TTM 120 kg (264 lb.)
IIT and Platen 21 kg (46 lb.)
DADF 14 kg (31 lb.)
Finisher 35 kg (77 lb.)
Network Controller (DC 3535 only) 6 kg (13 lb.)
Table 5 Paper Capacities (WC M24)
Specification Paper Trays 1 - 4 Tray 5 (Bypass)
Paper Sizes Tray 1 & 2 (TTM); Tray 1 -4 (3TM)
• Min: A5 SEF (148 x 210 mm)
• Max: A3/11 x 17 in.
Trays 3 & 4 (TTM only)
• A4, 8.5 x 11 in., and B5 LEF
only
Paper
• Min.: 100 x 140 mm (postcard)
• Max: 305 x 483 mm/12 x 19 in.
Envelopes
• Min.: 98 x 190 mm (Monarch 7
3/4 size)
Paper Weights Optimum: 24 lb./90 gsm
Range: 64 - 220 gsm
Range: 55 - 220 gsm
Capacities 24 lb.
(90 gsm)
TTM: 3040 sheets total:
• Tray 1: 520 sheets
• Tray 2: 520 sheets
• Tray 3: 867 sheets
• Tray 4: 1133 sheets
3TM: 2080 sheets total:
• Tray 1: 520 sheets
• Tray 2: 520 sheets
• Tray 3: 520 sheets
• Tray 4: 520 sheets
100 sheets
Table 3 Product Codes WC M24
Item Product Code
