Xerox DocuColor 2240 Service Manual

09/03
6-135
DC 3535/2240/1632, WC M24
Product Specs.
General Procedures and Information
Initial issue
Copy Speed
WorkCentre M24
• B/W (plain paper; simplex; fed from Tray 1)
– letter size LEF: 24 ppm
– letter size SEF: 20 ppm
– legal size: 17 ppm
– A3/11x17 in.: 15 ppm
• Color (plain paper; simplex; fed from Tray 1)
– letter size LEF: 13 ppm
– letter size SEF: 11 ppm
– legal size: 9 ppm
– A3/11x17 in.: 9 ppm
DocuColor 1632
• B/W (plain paper; simplex; fed from Tray 1)
– letter size LEF: 32 ppm
– letter size SEF: 24 ppm
– legal size: 20 ppm
– A3/11x17 in.: 17 ppm
• Color (plain paper; simplex; fed from Tray 1)
– letter size LEF: 16 ppm
– letter size SEF: 13 ppm
– legal size: 11 ppm
– A3/11x17 in.: 9 ppm
DocuColor 2240
• B/W (plain paper; simplex; fed from Tray 1)
– letter size LEF: 40 ppm
– letter size SEF: 30 ppm
– legal size: 24 ppm
– A3/11x17 in.: 20 ppm
• Color (plain paper; simplex; fed from Tray 1)
– letter size LEF: 22 ppm
– letter size SEF: 16 ppm
– B4/legal size: 13 ppm
– A3/11x17 in.: 11 ppm
DocuColor 3535
• B/W or Color (plain paper; simplex; fed from Tray 1)
– letter size LEF: 35 ppm
– letter size SEF: 26 ppm
– legal size: 21 ppm
– A3/11x17 in.: 17 ppm
FCOT/FPOT
First Copy Output Time (original on platen); 8.5” x 11” (A4); Tray 1;
• Color - 12.3 sec. max (DC 2240/1632); 13.5 sec (DC 3535)
Table 6 Paper Capacities (DC 2240/1632)
Specification Paper Trays 1 - 4 Tray 5 (Bypass)
Paper Sizes Trays 1 & 2
• Min.: A5 SEF (148 x 210 mm)
• Max: A3/11 x 17 in.
Trays 3 & 4
• A4, 8.5 x 11 in., and B5 LEF
only
Paper
• Min.: 100 x 140 mm (postcard)
• Max: 305 x 483 mm/12 x 19 in.
Envelopes
• Min.: 98 x 190 mm (Monarch 7
3/4 size)
Paper Weights Optimum: 24 lb./90 gsm
Range: 64 - 105 gsm
Range: 55 - 220 gsm
Capacities 24 lb.
(90 gsm)
3040 sheets total:
• Tray 1: 520 sheets
• Tray 2: 520 sheets
• Tray 3: 867 sheets
• Tray 4: 1133 sheets
100 sheets
Table 7 Paper Capacities (DC 3535)
Specification Paper Trays 1 - 4 Tray 5 (Bypass)
Paper Sizes Tray 1 & 2 (TTM); Tray 1 -4 (3TM)
• Min: A5 SEF (148 x 210 mm)
• Max: A3/11 x 17 in.
Trays 3 & 4 (TTM only)
• A4, 8.5 x 11 in., and B5 LEF
only
Paper
• Min.: 100 x 140 mm (postcard)
• Max: 305 x 483 mm/12 x 19 in.
Envelopes
• Min.: 98 x 190 mm (Monarch 7
3/4 size)
Paper Weights Optimum: 24 lb./90 gsm
Range: 64 - 220 gsm
Range: 55 - 220 gsm
Capacities 24 lb.
(90 gsm)
TTM: 3120 sheets total:
• Tray 1: 520 sheets
• Tray 2: 520 sheets
• Tray 3: 910 sheets
• Tray 4: 1170 sheets
3TM: 2080 sheets total:
• Tray 1: 520 sheets
• Tray 2: 520 sheets
• Tray 3: 520 sheets
• Tray 4: 520 sheets
95 sheets
