Status Indicator RAPs
9-926 Drum Cartridge (K) End Of Life
The Drum Cartridge (K) needs to be replaced.
Procedure
Replace the Black Drum Cartridge (refer to Section 6, Machine Consumables). The problem
is corrected.
YN
Replace the MCU PWB. (PL 13.1).
Return to Service Call Procedures.
9-927 Change Drum Cartridge (C) End Of Life
The Drum Cartridge (C) needs to be replaced.
Procedure
Replace the Cyan Drum Cartridge (refer to Section 6, Machine Consumables). The problem
is corrected.
YN
Replace the MCU PWB. (PL 13.1).
Return to Service Call Procedures.
