09/03

2-215

DC 3535/2240/1632, WC M24

9-928, 9-929

Status Indicator RAPs

Initial issue

9-928 Drum Cartridge (M) End Of Life

The Drum Cartridge (M) needs to be replaced.

Procedure

Replace the Magenta Drum Cartridge (refer to Section 6, Machine Consumables). The prob-

lem is corrected.

Replace the MCU PWB. (PL 13.1).

Return to Service Call Procedures.

9-929 Drum Cartridge (Y) End Of Life

The Drum Cartridge (Y) needs to be replaced.

Procedure

Replace the Yellow Drum Cartridge (refer to Section 6, Machine Consumables). The problem

is corrected.

Replace the MCU PWB. (PL 13.1).

Return to Service Call Procedures.
