Repairs and Adjustments
3. Make sure when installing the Plate, that the Cable Tie (Strain Relief) is inside the Bracket
and the cable is routed through the notch (Figure 9).
Figure 9 Routing the Cable
Notch
Cable Tie
(Strain Relief)
Bracket
