09/03
4-139
DC 3535/2240/1632, WC M24
REP 12.18
Repairs and Adjustments
Initial issue
2. Engage the solenoid pawl (Figure 5).
Figure 5 Engaging Pawl with Slot
Rotate Cam so
Pawl engages
Slot
