1-20
No CCM from some remote MEPs is received.
One or more streams of error CCMs is received. The last-received CCM:
Maintenance domain:mdtest1
Maintenance association:matest1
MEP:5 Sequence Number:0x50A
Received Time: 02/3/6 13:01:34
One or more streams of cross-connect CCMs is received. The last-received CCM:
Maintenance domain:mdtest1
Maintenance association:matest1
MEP:6 Sequence Number:0x63A
Received Time: 02/3/6 13:01:34
Some other MEPs are transmitting the RDI bit.
Table 1-8 display cfd mep command output description
Field Description
Interface Interface that an MD belongs to
Maintenance domain MD that a MEP belongs to
Maintenance association MA that a MEP belongs to
Level Level of the MD
VLAN VLAN that the MA belongs to
Direction Direction of the MEPs
Administrative state State of MEP, either Active or Inactive
CCM send Whether the MEP sends CCM
FNG state
z State of FNG (Fault Notification Generator), which can be: FNG_RESET
z FNG_DEFECT
z FNG_REPORT_DEFECT,
z FNG_DEFECT_REPORTED
z FNG_DEFECT_CLEARING
CCM Information related to CCM
Current state
State of CCMs sent, which can be:
z CCI_IDLE
z CCI_WAITING
Interval Interval to send CCM
SendCCM Number of CCMs that have been sent by the MEPs
Loopback Information related to Loopback
NextSeqNumber Sequence number of the next LBM to be sent
SendLBR
Number of LBRs that have been sent. If the MEP is inward-facing, the number
of LBRs will not be counted.
ReceiveInOrderLBR Number of LBR messages received in correct sequence
ReceiveOutOrderLBR Number of LBR messages received out of order
Linktrace Information related to linktrace
