H3C S3100 Series Command Manual

1-2
Table 1-1 Description on the fields of the display poe interface command
Field Description
Port power enabled PoE is enabled on the port
Port power ON/OFF The power on the port is on/off
Port power status
PoE status on the port:
z user command set port to off: PoE to the port is turned off by the user
z Standard PD was detected: A standard PD is detected
z Legacy PD was detected: A non-standard PD is detected
z detection is in process: PDs are being detected
Port power mode
PoE mode on the port:
signal: PoE through the signal cable
Port PD class Class of power to the PD
Port power priority
PoE priority of the port:
z critical: The highest
z high: High
z low: Low
Port max power The maximum available power on the port
Port current power The current power on the port
Port average power The average power on the port
Port peak power The peak power on the port
Port current The current on the port
Port voltage The voltage on the port
# Display the PoE status of all ports.
<Sysname> display poe interface
PORT INDEX POWER ENABLE MODE PRIORITY STATUS
Ethernet1/0/1 off disable signal low user command set port to off
Ethernet1/0/2 off disable signal low user command set port to off
Ethernet1/0/3 off disable signal low user command set port to off
Ethernet1/0/4 off disable signal low user command set port to off
Ethernet1/0/5 off disable signal low user command set port to off
Ethernet1/0/6 off disable signal low user command set port to off
……
<Omitted>
Table 1-2 Description on the fields of the display poe interface command
Field Description
PORT INDEX Port index
POWER Power status on the port: ON/OFF
ENABLE PoE enabled/disabled status on the port
MODE
PoE mode on the port:
z signal: PoE through the signal cable
z spare: PoE through the spare cable
