09/03
6-108
DC 3535/2240/1632, WC M24
dC330
Initial issue
General Procedures and Information
009-101 Toner_Y New CRU Connection of color is open (The CRU in
use is present, or it is not present). Low=new,
High=old
009-102 Toner_M New CRU Connection of color is open (The CRU in
use is present, or it is not present). Low=new,
High=old
009-103 Toner_C New CRU Connection of color is open (The CRU in
use is present, or it is not present) Low=new,
High=old
009-104 Toner_K New CRU Connection of color is open (The CRU in
use is present, or it is not present) Low=new,
High=old
009-150 TNR FULL SNR ON = High
009-151 #Y_CRU detect CRU is installed
009-152 #M_CRU detect CRU is installed
009-153 #C_CRU detect CRU is installed
009-154 #K_CRU detect CRU is installed
009-200 2nd BTR Retract Sensor Retraction. ON = Low
009-201 POB Sensor Paper detected. ON = Low
009-203 1st BTR Retract Sensor Retraction. ON = Low
010-101 Fuser Exit Paper detected. ON = High
010-102 Full Paper Stack Sensor NotFull. ON = Low
012-100 IOT Regi Clutch Clutch OFF. ON = High
012-101 Compiler Tray Exit Sensor Paper detected. ON = High
012-102 Compiler Paper Sensor Paper detected. ON = High
012-103 H-Tra Ent. Sensor Paper detected. ON = High
012-104 H-Tra Exit Sensor Paper detected. ON = High
012-200 Stacker Paper Sensor Paper detected. ON = High
012-201 Stacker Height Sensor Higher than the detection surface. ON = High
012-202 Stacker Upper Limit Sensor Upper Limit position. ON = High
012-204 Stacker Stack A Sensor Non-transmissive position. ON = High
012-205 Stacker Stack B Sensor Non-transmissive position. ON = High
012-207 Staple Head Home Sensor Not at Home position. ON = High
012-208 Low Staple Switch Low Staple. ON = High
012-209 Staple Ready Sensor Not at Ready position. ON = High
012-210 Eject Clamp Home Sensor Not at Home Position (Roller is down). ON = High
012-211 Set Clamp Home Sensor Not at Home Position (transmissive). ON = High
012-212 Rear Tamper Home Sensor Home position. ON = High
012-215 H-Tra IOT Full Paper Sensor No paper. ON = High
012-216 Front Tamper Home Sensor Home position. ON = High
012-217 Decurler Cam Position Sen-
sor
Not at Home Position (transmissive). ON = High
Table 1 Input Component Control Codes
Code Name Description
012-224 Stapler Move Sensor Non-transmissive position. ON = High
012-225 Stapler Front Corner Sensor Front Corner position. ON = High
012-300 Front Cover Interlock Switch Open. ON = High
012-301 Top Cover Interlock Switch Open. ON = High
012-302 Docking Interlock Sensor Docking release. ON = High
012-305 H-Tra Interlock Sensor Open. ON = High
Table 2 Output Component Control Codes
Code Name Description Conflicts
001-001 Delayed_off Delay Relay
001-003 Flicker Energize triac to switch in Flicker Resistor.
(220VAC - DC3535 only)
004-001 Steering Motor Reswitch the Steering Cam to Home posi-
tion once and operate it at half cycle after
that.
004-005
004-002 IBT Motor (104mm/
sec.)
Operate with the IBT Assy. removed to pre-
vent Transfer Belt damage.
004-012,
004-013
004-003 Drum Motor YMC
(104mm/sec.)
Remove all Drum Cartridges before ener-
gizing to prevent Belt damage.
004-004 Main Motor
(104mm/sec.)
Rotate at medium speed. Operate the
motor with the 2nd BTR nipped, or the LH
Cover opened. Otherwise, the 2nd BTR
might damage the belt.
004-007,
004-008
004-005 Steering Motor
Home Position
Returns Steering Cam to home position
ON = Low. Operate with the IBT Assy.
removed to prevent Transfer Belt damage.
004-001
004-006 Drum Motor K
(104mm/sec.)
Remove all Drum Cartridges before ener-
gizing to prevent Belt damage.
004-004,
004-009
004-007 Main Motor (52mm/
sec.)
Rotate at low speed. Operate the motor
with the 2nd BTR nipped, or the LH Cover
opened. Otherwise, the 2nd BTR might
damage the belt.
004-004,
004-008
004-008 Main Motor (high
speed)
Rotate at high speed. Operate the motor
with the 2nd BTR nipped, or the LH Cover
opened. Otherwise, the 2nd BTR might
damage the belt.
004-004,
004-007
004-009 Drum Motor K
(52mm/sec.)
Rotate at low speed. Remove all Drum Car-
tridges before energizing to prevent Belt
damage.
004-006,
004-010
004-010 Drum Motor K (high
speed)
Rotate at high speed. Remove all Drum
Cartridges before energizing to prevent
Belt damage.
004-006,
004-009
Table 1 Input Component Control Codes
Code Name Description
To Next Page
