Xerox DocuColor 2240 Service Manual

09/03
6-110
DC 3535/2240/1632, WC M24
dC330
Initial issue
General Procedures and Information
008-011 Dup Motor
(200.1mm/sec.)
Long
8-009, 010,
012, 053, 054,
055, 056
008-012 Dup Motor
(104mm/sec.) Long
8-009,
010,011, 053,
054, 055, 056
008-021 3TM TA Motor
(52mm/sec.)
Start operation. Switches OFF automati-
cally at 1000msec.
8-022, 023,
024, 025, 026,
027, 028
008-022 3TM TA Motor
(104mm/sec.)
Start operation. Switches OFF automati-
cally at 1000msec.
8-021, 023,
024, 025, 026,
027, 028
008-023 3TM TA Motor
(192mm/sec.)
Start operation. Switches OFF automati-
cally at 1000msec.
8-021, 022,
024, 025, 026,
027, 028
008-024 3TM TA Motor
(370mm/sec.)
Start operation. Switches OFF automati-
cally at 1000msec.
8-021, 022,
023, 025, 026,
027, 028
008-025 3TM TA Motor
(52mm/sec.) Long
8-021, 022,
023, 024, 026,
027, 028
008-026 3TM TA Motor
(104mm/sec.) Long
8-021, 022,
023, 024, 025,
027, 028
008-027 3TM TA Motor
(192mm/sec.) Long
8-021, 022,
023, 024, 025,
026, 028
008-028 3TM TA Motor
(370mm/sec.) Long
8-021, 022,
023, 024, 025,
026, 027
008-029 TTM TA Motor
(52mm/sec.)
Start operation. Switches OFF automati-
cally at 1000msec.
8-030, 031,
032, 033, 034,
035, 036
008-030 TTM TA Motor
(104mm/sec.)
Start operation. Switches OFF automati-
cally at 1000msec.
8-029, 031,
032, 033, 034,
035, 036
008-031 TTM TA Motor
(192mm/sec.)
Start operation. Switches OFF automati-
cally at 1000msec.
8-029, 030,
032, 033, 034,
035, 036
008-032 TTM TA Motor
(370mm/sec.)
Start operation. Switches OFF automati-
cally at 1000msec.
8-029, 030,
031, 033, 034,
035, 036
008-033 TTM TA Motor
(52mm/sec.) Long
8-029, 030,
031, 032, 034,
035, 036
Table 2 Output Component Control Codes
Code Name Description Conflicts
008-034 TTM TA Motor
(104mm/sec.) Long
8-029, 030,
031, 032, 033,
035, 036
008-035 TTM TA Motor
(192mm/sec.) Long
8-029, 030,
031, 032, 033,
034, 036
008-036 TTM TA Motor
(370mm/sec.) Long
8-029, 030,
031, 032, 033,
034, 035
008-037 Regi Clutch Switches on. Switches off automatically at
400msec.
None
008-038 #1TA Clutch Switches on. Switches off automatically at
400msec.
None
008-042 Invert Clutch CW Switches on in output direction. Switches
OFF automatically at 400msec.
None
008-043 Invert Clutch CCW Switches on in Invert direction. Switches
OFF automatically at 400msec.
None
008-047 TTM TM Motor2
(370mm/sec.)
Start operation. Switches OFF automati-
cally at 1000msec.
None
008-048 TTM TM Motor2
(370mm/sec.) Long
. None
008-049 MOB2LED_CHNG MOB SNR2 LED Light quantity switching
signal, Light quantity UP (increase voltage)
at PORT H. ON = ANA Output LED2 Light
quantity UP
None
008-050 MOB2LED_ON MOB SNR2 LED ON. ON = ANA output None
008-051 MOB1LED_CHNG MOB SNR1 LED Light quantity switching
signal, Light quantity UP (increase voltage)
at PORT H. ON = ANA Output LED1 Light
quantity UP
None
008-052 MOB1LED_ON MOB SNR1 LED ON. ON = ANA output None
008-053 Dup Motor
(373.2mm/sec.)
Start operation. Switches OFF automati-
cally at 1000msec.
8-009, 010,
011, 012, 054,
055, 056
008-054 Dup Motor
(194mm/sec.)
Start operation. Switches OFF automati-
cally at 1000msec.
8-009, 010,
011, 012, 053,
055, 056
008-055 Dup Motor
(373.2mm/sec.)
Long
8-009, 010,
011, 012, 053,
054, 056
008-056 Dup Motor
(194mm/sec.) Long
8-009, 010,
011, 012, 053,
054, 055
009-001 #Y_Disp MOT Y Color Disp. MOT turns ON, and switches
OFF automatically after 5sec.
-
Table 2 Output Component Control Codes
Code Name Description Conflicts
