Xerox DocuColor 2240 Service Manual

09/03
6-111
DC 3535/2240/1632, WC M24
dC330
General Procedures and Information
Initial issue
009-002 #M_Disp MOT M Color Disp. MOT turns ON, and switches
OFF automatically after 5sec.
-
009-003 #C_Disp MOT C Color Disp. MOT turns ON, and switches
OFF automatically after 5sec.
-
009-004 #K_Disp MOT K Color Disp. MOT turns ON, and switches
OFF automatically after 5sec.
-
009-005 #Y_DB DC Y Color Developer Bias DC Component
Output
-
009-006 #M_DB DC M Color Developer Bias DC Component
Output
-
009-007 #C_DB DC C Color Developer Bias DC Component
Output
-
009-008 #K_DB DC K Color Developer Bias DC Component
Output
-
009-009 #YM_DB AC YM Color Developer Bias AC Component
Output
-
009-012 #CK_DB AC CK Color Developer Bias AC Component
Output
-
009-013 Dev_CL The clutch for driving K Color turns ON,
and switches OFF automatically after 5
sec.
-
009-014 Dev_MOT Normal-
speed
Switches off automatically after 5 sec. 009-016,-017
009-016 Dev_MOT Half-
speed
Switches off automatically after 5sec. 009-014, -017
009-017 Dev_MOT High-
speed
Switches off automatically after 5sec. 009-016, -017
009-018 Dev bias AC
enable
Switch on before starting BCR DC for each
color.
009-026 #Y_BCR DC High voltage output value of BCR DC_Y.
ON = PWM
009-030
009-027 #M_BCR DC High voltage output value of BCR DC_M.
ON = PWM
009-031
009-028 #C_BCR DC High voltage output value of BCR DC_C.
ON = PWM
009-032
009-029 #K_BCR DC High voltage output value of BCR DC_K.
ON = PWM
9-33
009-030 #Y_BCR AC High voltage output value of BCR AC_Y.
ON = PWM
009-026
009-031 #M_BCR AC High voltage output value of BCR AC_M 009-027
009-032 #C_BCR AC High voltage output value of BCR AC_C 009-028
009-033 #K_BCR AC High voltage output value of BCR AC_K 009-029
009-034 AGT MOT Agitator MOT ON
009-035 CRUM PWR Power ON for CRUM-YMCK
Table 2 Output Component Control Codes
Code Name Description Conflicts
009-037 Dev DC chg (K)
009-038 BCR ACDC K CHG DEVE_AC_K changes at connector termi-
nals trailing.
009-039 BCRAC Clock Frequency signal common to BCR AC All
Colors.
009-040 ROS Shutter Close ROS Shutter: Rotates in Close direction
(Brush: Contact direction).
009-041
009-041 ROS Shutter Open ROS Shutter: Rotates in Open direction
(Brush: Retract direction). ON = H
009-040
009-042 #K_Erase Lamp K ERASE LAMP lit.
009-045 #YMC_Erase Lamp YMC ERASE LAMP lit.
009-051 2nd BTR Contact BTR2 Retract MOT. Switches off 800ms
after the Retract SNR detected the Contact
Position (High).
-
009-052 2nd BTR Retract Switches off 60ms after the Retract SNR
detected the Retract Position (Low).
-
009-053 De Tack Saw HV Turn on DTS HV. -
009-054 1st BTR Contact Switches off 100ms after the Retract SNR
detected the Contact Position (High).
-
009-055 1st BTR Retract Switches off 100ms after the Retract SNR
detected the Retract Position (Low).
-
009-056 2nd BTR Select selects polarity of bias voltage -
009-076 Specular reflection
LED
When the Specular Reflection LED of ADC
SNR turns ON and YMC density is
detected.
-
009-077 Diffusion reflection
LED
When the Diffusion Reflection LED of ADC
SNR turns ON and K density is detected.
-
009-078 ADC Sensor Shut-
ter Open
Switches off automatically after 100msec. 009-079
009-079 ADC Sensor Shut-
ter Close
Switches off automatically after 100msec. 009-078
009-080 ATC Sensor 5V ON 5V Power supply to ATC SNR. -
010-001 OCT Motor (CW) Switches on forward and switches off auto-
matically at 150msec.
010-002
010-002 OCT Motor (CCW) Switches on reverse and switches off auto-
matically at 150msec.
010-001
012-001 Main Drive Motor
On/Off
012-071
012-010 Rear Tamper Motor
Low Front On/Off
Switches off automatically after 100pulses. 012-011, 012-
012, 012-013,
012-014, 012-
015
Table 2 Output Component Control Codes
Code Name Description Conflicts
