Xerox DocuColor 2240 Service Manual

09/03
4-117
DC 3535/2240/1632, WC M24
REP 12.10
Repairs and Adjustments
Initial issue
5. Move the PWB Chassis down (Figure 4).
Figure 4 Moving PWB Chassis Down
6. Remove Rear Rail Mounting Screws (2) (Figure 5).
Figure 5 Removing Rear Rail Mounting Screws
1
Disconnect
P848 and
remove from
Guide
2
Disconnect
P849 and
P846 and
remove from
Guide
3
Loosen Screw
4
Remove
Screws (2)
and allow
PWB Chas-
sis to hang
down
Remove
Screws (2)
