H3C S3100 Series Command Manual

1-25
The default DSCP-precedence-to-local-precedence mapping tables as shown in Table 1-12.
Table 1-12 The default DSCP-precedence-to-local-precedence mapping table
DSCP Local precedence
0 to 15 0
16 to 31 1
32 to 47 2
48 to 63 3
Related command: display qos dscp-local-precedence-map.
Example
# Modify the DSCP-precedence-to-local-precedence mapping table according to
Table 1-13.
Table 1-13 A DSCP-precedence-to-local-precedence mapping table
DSCP Local precedence
0 to 15 1
16 to 31 1
32 to 47 2
48 to 63 3
The configuration procedure is as follows:
<Sysname> system-view
System View: return to User View with Ctrl+Z.
[Sysname] qos dscp-local-precedence-map 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 : 1
# Display the configuration result.
[Sysname] display qos dscp-local-precedence-map
dscp-local-precedence-map:
dscp : local-precedence(queue)
----------------------------------------------
0 : 2
1 : 2
2 : 2
3 : 2
4 : 2
5 : 2
6 : 2
7 : 2
8 : 2
9 : 2
10 : 2
11 : 2
12 : 2
13 : 2
