Siemens SIMATIC NET Configuration Manual

Network structures
6.2 VLAN
SCALANCE W760/W720 to IEEE 802.11n Command Line Interface
238 Configuration Manual, 10/2015, C79000-G8976-C351-05
Syntax
Call up the command with the following parameters:
ports
(
[<interface-type><0/a-b,0/c,...>]
[<interface-type><0/a-b,0/c,...>]
)
[
untagged<interface-type> <0/a-b,0/c,...>
(
[<interface-type><0/a-b,0/c,...>] [all]
)
]
[
forbidden<interface-type><0/a-b,0/c,...>
[<interface-type><0/a-b,0/c,...>]
]
[name<vlan-name>]
The parameters have the following meaning:
Parameter
Description
Range of values / note
interface-type
Type or speed of the interface
•
fastethernet
/a-b,0/c,...
Port no. of the interface
Enter a valid interface name
/a-b,0/c,...
Port no. of the interface
Enter a valid interface name
untagged
Keyword for interfaces or ports that transfer
data packets without VLAN marking
-
all
Specifies that all interfaces or ports are set to
"untagged"
-
forbidden
Keyword for forbidden interfaces or ports
-
name
Keyword for the name assignment
-
vlan-name
Name of the VLAN
max. 32 characters
Result
The settings are enabled.
Further notes
You display details of the function with the show vlan command.
You reset the settings with the
no ports command.
