Network structures
6.3 Spanning Tree
SCALANCE W760/W720 to IEEE 802.11n Command Line Interface
248 Configuration Manual, 10/2015, C79000-G8976-C351-05
show spanning-tree root
Description
This command shows the settings of the root bridge for the spanning tree function.
You are in the User EXEC mode or in the Privileged EXEC mode.
The command prompt is as follows:
cli> or cli#
Call up the command with the following parameters:
show spanning-tree root
[{address|cost|forward-time|id|max-age|port|priority|detail}]
The parameters have the following meaning:
Shows the MAC address of the root bridge
Shows the costs of the connection to the root bridge.
Shows the time that the bridge is in the listening mode when changing from
the blocking mode to the learning mode
Shows the ID of the root bridge
Shows the maximum age of the data packet after which it is deleted
Shows the interface via which the spanning tree is set up
Shows the priority of the bridge
Shows detailed information about the root bridge
The settings of the root bridge for the spanning tree function are displayed.
