Network structures
6.1 WLAN
SCALANCE W760/W720 to IEEE 802.11n Command Line Interface
Configuration Manual, 10/2015, C79000-G8976-C351-05
133
For information on identifiers of addresses and interfaces, refer to the section "Interface
identifiers and addresses (Page 25)".
The list of wireless channels available for establishing a wireless link to the relevant WLAN
interface is displayed.
show wlan antennas
Description
This command shows the antenna settings for the SCALANCE W700 device, for example
cable length.
You are in the User EXEC mode or in the Privileged EXEC mode.
The command prompt is as follows:
cli> or cli#
Call up the command with the following parameters:
show wlan antennas <wlan 0/X>
The parameter has the following meaning:
For information on identifiers of addresses and interfaces, refer to the section "Interface
identifiers and addresses (Page 25)".
The antenna settings of the relevant WLAN interface are displayed.
