Network structures
6.2 VLAN
SCALANCE W760/W720 to IEEE 802.11n Command Line Interface
Configuration Manual, 10/2015, C79000-G8976-C351-05
227
base bridge-mode
Description
With this command, you configure whether or not the device is configured as a bridge
according to IEEE 802.1D for the Spanning Tree protocol or according to IEEE 802.1Q for a
virtual bridged LAN.
You are in the Global Configuration mode.
The command prompt is as follows:
cli(config)#
Call up the command with the following parameters:
base bridge-mode {dot1d-bridge|dot1q-vlan}
The parameters have the following meaning:
Sets the mode of the device to "transparent"
for the Spanning Tree protocol.
Default setting
sets the mode of the device to "VLAN-aware"
for a virtual bridged LAN.
-
The device mode is configured.
You display the status of this function and other information with the show vlan device info
command.
