Network structures
6.3 Spanning Tree
SCALANCE W760/W720 to IEEE 802.11n Command Line Interface
Configuration Manual, 10/2015, C79000-G8976-C351-05
251
Result
The spanning tree function is disabled.
Further notes
You enable the spanning tree function with the spanning-tree command.
You can display the status of this function and other information with the
show spanning-tree
detail
command.
You can display information about active ports with the
show spanning-tree active
command.
6.3.3.3
spanning-tree compatibility
Description
With this command, you configure the compatibility version of the protocol that will be used
by the spanning tree function.
Requirement
You are in the Global Configuration mode.
The command prompt is as follows:
cli(config)#
Syntax
Call up the command with the following parameters:
spanning-tree compatibility {stp|rst|mst}
The parameters have the following meaning:
Parameter
Description
Range of values / note
stp
The version is compatible with the
Spanning Tree protocol
-
rst
The version is compatible with the
Rapic Spanning Tree protocol
Default: enabled
mst
The version is compatible with the
Multiple Spanning Tree protocol
-
Result
The compatibility version of the protocol is selected.
